KZO-50
Main Performance Data
Oxygen output: 50Nm3/h
Oxygen Purity: 99.6%
Working pressure: 1.2MPA
Starting time: ~5h
Total power: 98KW
Power supply: 420V/220V/60Hz
KZO-60y
Main technical parameters:
Liquid oxygen output: 63L/h (translation gaseity oxygen is: 50Nm3/h)
Liquid oxygen Purity: 99.6%
Working pressure: <1.05MPA
Starting time: ~6h
Total power: 163.5KW
Power supply: 380V/220V/50Hz
KDON-350/700
Model: KDON-350/700
Name of equipment: KDON-350/1000 Air Separation equipment
Quantity of Air treated: 2800m3/h
Oxygen output: 350m3/h
Oxygen purity: 99.6%
Nitrogen output: 700m3/h
Nitrogen purity: 99.99%
Period of continuous operation: One year
Time of starting: 24h
Power consumption: 0.6kwh/Nm3O2
KDONAr-1000 Y /(1000Y)/30Y Liquid Air Separation Plant
2.1 Main Performance Data
Case 1:
Products Production Capacities
Nm3/h Purity
Liquid Oxygen LOX 1000 99.6%
Liquid Argon LAr 30 99.999%(3PPmO2, 2PPmN2)
Case 2
Products Production Capacities
Nm3/h Purity
Liquid Nitrogen LIN 1000 ≤ 10ppmO2
Case 3
Products Production Capacities
Nm3/h Purity
Liquid Oxygen LOX 500 99.6%
Liquid Nitrogen LIN 500 ≤ 10ppmO2
Liquid Argon LAr 15 99.999%(3PPmO2, 2PPmN2)
Note:
1. Nm3/h means the gas volumetric flow at 0.1013 MPA (A) and 0.
2. The liquid output is converted into the gas volumetric flow at 0.1013 MPA (A) and 0.
2.2 Starting Time: ~8 hr
2.3 De-riming Time ~24hr
2.4 Operation period (duration between two major heating) 2 years
KDONAr-4000 /4000/100
Main Performance Data
Case 1:
Products Production Capacities
Nm3/h Purity
Oxygen 4000 99.6%
Case 2
Products Production Capacities
Nm3/h Purity
Nitrogen 4000 ≤ 10ppmO2
Case 3
Products Production Capacities
Nm3/h Purity
Liquid Argon LAr 100 99.999%(3PPmO2, 2PPmN2)
Note: Nm3/h means the gas volumetric flow at 0.1013 MPA (A) and 0
2.2 Starting Time: ~36hr
2.3 Operation period (duration between two major heating) 2 years
KDN-1140Y
1. Performance parameter
1.1 output and purity
Product Equivalent to gas production
(Nm3/h) Equivalent to liquid production
(kg/h or L/h) purity Outlet pressure/ temperature
Liquid nitrogen 800 1000 1140 O2≤ 10ppm 0.4MPA/-193
1.2 running period ≥ 2 yeas
1.3 heat and unfreeze 24 hours
1.4 start time 10 hours
Handan Dyon Air Separation Plant Co., Ltd. specializes in air separation plants, dissolved acetylene equipment, chemical tail gas recovery manufacturing, development and service. The company has a research and development technical team being engaged in the low temperature equipment field for many years. In the long-term technology development and production practice, the researchers have accumulated rich experience.
Our main products include:
1. Air separation equipment
Mobile type oxygen and nitrogen cart
20-180m3 / h skid mounted type oxygen plant and nitrogen plant
Liquefaction plants in vitro
Liquid equipment (liquid oxygen, liquid nitrogen, liquid argon)
Small, medium, large type, full-low pressure energy-saving air separation plant
2. Dissolved acetylene equipment
3. Chemical exhaust recovery equipment
4. Low temperature technology used in development
5. 5-10m3/n Nitrous oxide equipment
Based on "quality reputation to survive, technology development to progress " principle, Handan Dyon Air Separation Plant Co., Ltd. Constantly exploits And innovates to ensure that customers construction quality, cycle and investment costs. The company maintains a relentless pursuit of improvement in every critical performance so as to serve customers throughout the world.
Handan Dyon Air Separation Plant Co., Ltd. is full of vigor and potential. We warmly welcome clients from all over the world to cooperate with us and develop worldwide markets together. As one of the largest air separation plants manufacturer in China, we can ensure high quality and competitive prices. We are glad to establish long-term business relationships with you on the basis of mutual benefit.
