Portable emergency generator(DG4000E)
DG4000E model: With 7 HP HR178FA diesel engine and 100% copper alternator ensure a 3.2KW rated output, and 3.5KW max. Output!
1. We are manufactory, could give best suggestions to customers also learn good idea from every good customer!
2. Professional general engineers and technical team.
3. Have spare parts for customers' exchange. Several type spare parts are made by ourself, it should be more competitive!
4. Warranty: Running 500 hours or one year. Can support free spare parts for reparing during warrenty time and also low than market price spare parts out of warrenty time!
5.100% copper good brand alternator, every spare parts suppliers are choosed extremely stricted, to control the quality well.
6. From engine to whole genset, we test every link of every product, have test machinery and test center.
7. Many spare parts are produced by ourselves, could save cost for customers greatly.
8. We welcome every customer visiting our factory and test our products.
We are professional generator manufacture, I think we must have one type even more can match what you need!
Professional manufacture of diesel engine(4-22HP), diesel generator(1.8-1000KW), diesel water pump(1.5-4INCH), small construction machine and so on.
Just send us your inquiry with what u need, we will highly appreciate it!
|
Model |
DG4000E |
|
Generator |
Frequency (HZ) |
50 |
60 |
|
Max.output (kw) |
3.3 |
3.5 |
|
Rated output (kw) |
3 |
3.3 |
|
Rated.AC voltage (V) |
120,220,230,120/240,220/380 |
|
Power factor |
1 |
|
DC output (V) |
12V/8.3A |
|
Phase |
Single phase or Three phase |
|
Alternator type |
Self-excited,2-pole,
Single phase or Three phase alternator |
|
Starting system |
Electric |
|
noise level (at 7m) |
80-85 |
|
Fuel tank capacity (L) |
12.5 |
|
Continuous work (hr) |
10 |
8.5 |
|
Engine |
Model |
HR178FA |
|
Engine type |
single-cylinder, vertical,
4-stroke air-cooled diesel engine |
|
Bore×stroke (mm) |
78×64 |
|
Fuel |
0# or -10# light diesel oil |
|
Lubrication oil volume (L) |
1.1 |
|
Combustion system |
Direct Injection |
|
Standard feature |
Voltmeter |
yes |
|
AC Output Socket |
2 |
|
Ac circuit breaker |
yes |
|
Oil warning light |
yes |
|
Oil alert |
yes |
|
Optional feature |
DC circuit breaker |
Optional |
|
Calculagraph |
Optional |
|
Big wheel |
Optional |
|
Three phase voltage |
Optional |
|
Current meter |
Optional |
|
ATS |
Optional |
|
Remote control |
Optional |
|
Welding |
no |
|
Dimension |
Dimension(L×W×H)(mm) |
700×480×570 |
|
Net weight (kg) |
69 |
|
20FT |
130 |
