SHICONG SCREW AIR COMPRESSOR FEATURES:
1. Stable quality
2. Competitive price
3. Complete after-service
4. ISO Certificates
Stable Quality
Supporting by the factory, Shicong Screw air compressor can promise the soonest delivery time & stable quality.
Competitive price
Compared to the same standard screw air compressor, Shicong is forcusing on the low and middle consumption market, would like to offer the most favourable price for our customers.
Complete Service
Shicong machine would like to offer the following services
---Installation Service
---Trainning Service
--- Maintenance Service
For reference, here is the Specification for Shicong Screw air compressor
| Model | SC-7A | SC-10A | SC-15A | SC-20A | SC-25A | SC-30A | SC-40A | SC-50A | SC-60A | SC-75A | SC-100A | SC-30A | SC-50A | SC-75A | SC-100A | SC-120A | SC-150A/W | SC-175A/W | SC-200W |
| Freee air | 0.85/0.7 | 1.2/0.7 | 1.6/0.7 | 2.5/0.7 | 3.2/0.7 | 3.8/0.7 | 5.2/0.7 | 6.8/0.7 | 7.3/0.7 | 10.0/0.7 | 13.5/0.7 | 3.8/0.7 | 6.8/0.7 | 10.0/0.7 | 13.5/0.7 | 16.1/0.7 | 21/0.7 | 25.2/0.7 | 28.7/0.7 |
| compressor/Discharge pressure (m³/min/Mpa) | 0.75/0.8 | 1.1/0.8 | 1.5/0.8 | 2.3/0.8 | 2.9/0.8 | 3.6/0.8 | 5.0/0.8 | 6.2/0.8 | 7.0/0.8 | 9.1/0.8 | 12.6/0.8 | 3.6/0.8 | 6.2/0.8 | 9.1/0.8 | 12.6/0.8 | 15.0/0.8 | 19.8/0.8 | 24/0.8 | 27.6/0.8 |
| 0.9/1.0 | 1.3/1.0 | 2.1/1.0 | 2.6/1.0 | 3.2/1.0 | 4.5/1.0 | 5.6/1.0 | 6.0/1.0 | 8.5/1.0 | 11.2/1.0 | 3.2/1.0 | 5.6/1.0 | 8.5/1.0 | 11.2/1.0 | 13.8/1.0 | 17/1.0 | 21/1.0 | 24.6/1.0 |
| 0.7/1.2 | 1.1/1.2 | 1.9/1.2 | 2.2/1.2 | 2.8/1.2 | 3.8/1.2 | 4.9/1.2 | 5.6/1.2 | 7.6/1.2 | 10.0/1.2 | 2.8/1.2 | 4.9/1.2 | 7.6/1.2 | 10.0/1.2 | 12.3/1.2 | 15.3/1.2 | 18.3/1.2 | 21.5/1.2 |
| No.of compression stage | single stage |
| Ambient temprerature | -5--+45ºC | 40 |
| Cooling Model | Air --Cooling | single stage | Air-Cooling&Water-Cooling |
| Discharge temperature (ºC) | Ambient temperature+15ºC |
| Lubricant (L) | 16 | 18 | 30 | 65 | 18 | 30 | 65 | 90 | 110 |
| Noise Level (Db) | 62±2 | 64±2 | 66±2 | 68±2 | 68±2 | 72±2 | 75±2 | 72±2 |
| Drive method | Multivee belt Driven | Direct Driven |
| Electricity (V/ph/Hz) | 380/3/50 |
| Power (KW) | 5.5 | 7.5 | 11 | 15 | 18.5 | 22 | 30 | 37 | 45 | 55 | 75 | 22 | 37 | 55 | 75 | 90 | 110 | 132 | 150 |
| Starting method | Y-Starter |
| Dimension:length/ | 800*720*950 | 950*800*1158 | 1150×900×1380 | 1300×1000*1478 | 1600*1170*1580 | 1380× | 1500 | 1900 | 2000 | Air-Cooling:2700 Water-Cooling:2250 | 2700× |
| width/height (mm) | 850× | 1000 | 1250 | 1250 | Air-Cooling:1620 Water-Cooling:1600 | 1600× |
| 1160 | 1330 | 1600 | 1670 | Air-Cooling :1860 Water-Cooling:1860 | 1860 |
| weight (kg) | 240 | 450 | 680 | 850 | 1700 | 620 | 850 | 1800 | 1900 | 2100 | 2900 | 3500 | 3900 |
| Air outlet Pipe Diameter (inch/mm) | 3/4" | 1" | 1 1/2" | 2" | 1 1/4" | 1 1/2" | 2 " | DN65 | DN80 |
380v/3ph/60hz, 220v/3ph/60hz/ 420v/3ph/50hz etc. are available.
Guangzhou SHICONG MACHINERY MANUFACTURING Co., Ltd is a professional enterprise supplier for Pneumatic Equipments. With best service, professional manufacturing factory, as well as experienced technician, SHICONG serves customers all around the world.
Thanks for the technologies from Germany and Italy, SHICONG continuously improved the manufacturing tech and unique inspection method according to the advanced European design concept. All of SHICONG products have be certified with ISO 9001, ISO14000. SHICONG machine can be extensively used in many fields such as mechanism, medical, textile, foodstuff, electricity, automobile, building materials and arms industry. For foreign market, SHICONG also exports to Southeast Asia, North America, more than 50 countries and regions.
