Advanced Oxygen Supply System for Military Working and Soliders

Solid Oxygen Generator
Dimension 140 mm (length)×140 mm (width) ×400mm (height)
Weight 15.5 kg
Range of application Atmospheric pressure of the external environment ≥0.06MPa
Oxygen supply time 35~45 min (oxygen production rate: 100L/min)
Gas quality index O2(≥99.5%); CO2 (no more than 1,000 ppm); CO (no more than 25ppm and 35ppm for the safety range of the human safety); others (CH4, metric oxide, chlorine etc.)(no more than 1 ppm); no foreign smell, complying with the physiological use requirement.
Supplied oxygen quantity Under the standard atmospheric pressure, the volume of the generated oxygen is about 3,000L (can meet the oxygen demand of 8 person each day and it is recommended that the use range of each product is ≤40).
Storage period ≤5 years (the regular inspection and maintenance should carried out each year)
Surface temperature of the solid oxygen generator when it is operating ≤150ºC(The recommended safe distance is 0.5m within 30min during the operation of the solid oxygen generator and after its operation)
Temperature at the oxygen outlet ≤80ºC
Remarks After the reaction, the main composition in the residual is sodium chloride.

Portable Oxygen Supply Unit
Model DGBY-1
Boundary dimension 273 mm (length)×182 mm (width)×96mm (height)
Packing dimension 450 mm (length)×353 mm (width)×132mm (height)
Weight 2.25 kg
Oxygen concentration 26-31%
Oxygen flow rate 3L/min
Oxygen production mode Oxygen permeable membrane
Operating temperature -20ºC-50ºC
Operating pressure 60-101Kpa
Power supply DV22.2V 4.4Ah
Supply time 3h
Operating noise 30dB

Intelligent Oxygen Supply Unit
Dimension 420 mm (length)×210mm (width) ×580mm (height)
Supplied oxygen quantity Under the standard atmospheric pressure, the volume of the generated oxygen is about 4,000L.
Oxygen concentration 18-23.5%
Oxygen production mode Oxygen candle
Oxygen supply reaction time 6-10min
Power supply 12V adapter for 220V
Storage time 8 years

Field
Military field: it can be applied to the aerospace, navigation, submarine, on-board, Second Artillery, individual combat in the special environments such as the high land, field and so on and barracks equipping and rescue of the hypoxia, poisonous or harmful places etc.; civilian field: it can be applied to the indoor air adjustment, emergency medical aid, self fire rescue and provide the oxygen for the operators in the closed space such as mine or petrochemical engineering space and so on.

Solid oxygen generator:
1. Accident under the mine
If the mine disasters such as collapse, water penetration etc. occur in the mine, the air in the mine will be quickly consumed and the trapped persons will often have asphyxia or shock when they are not timely rescued. If there is the solid oxygen generator in the mine, one can provide 8 persons with oxygen for 24-hour consumption, wining valuable time for the trapped persons.

2. Submarine oxygen supply
The operating time of the submarine under the water often depends on the residual oxygen quantity in the cabin. By using the solid oxygen generator to replace the traditional steel cylinder for oxygen supply, the stored oxygen quantity of the submarine is increased 10 times with the same volume. In order to reach the same oxygen production effect, the submarine only needs 1/10 space to store the solid oxygen generator, saving lots of valuable space in the cabin.

Intelligent Oxygen Supply Unit:
1.Household and office application
At present, most civilian oxygen supply units supply the oxygen by hand or supply the oxygen at the fixed time, which easily causes poisoning due to excessive oxygen. The intelligent oxygen supply unit adjusts the oxygen release according to the oxygen content in the air, providing the stable and healthy oxygen for the household and office.

Portable Oxygen Supply Unit:
1.March on the highland
During the marching and combat in the highland and field areas, the soldiers will easily have the symptoms of altitude stress to impact their fighting capacity. The weight of the individual portable oxygen supply unit is light and it is unnecessary to fill the raw materials, thus it is very applicable.

2. Emergency Medical Treatment
Under the emergency rescue case, the medical personnel cannot carry the large heavy oxygen supply unit. The portable oxygen supply unit is easy for carrying and it can immediately provide the valuable oxygen for those who are rescued.
