AC Alternator Silent Diesel Generators

AC Alternator Silent Diesel Generators
Price: US $ 12400/Piece
Trade Terms: FOB,CIF,EXW
Min Order: 1/Piece
Pay Type: L/C,T/T
AC Alternator Silent Diesel Generators
Specifications

1, Supply 20-1000KW
2. Advanced Control Panel
3.Water-cooled diesel engine
4. Service OEM Offered
5. ISO9001-2008


Why you chioce Jinan lvneng  Power equipment Co.,Ltd.cummins diesl generator?
1. we are professional manufacturer for gas/diesel generator set, over 15 years produced experience;
2. products range of gas engines/genset, including diesel engines, biomass generator sets, natural gas generator sets, biogas generator sets, coal mine gas generator set, etc. Products arrange from 5kw-3000kw ;
3. Our workshop covering more than 40000 square meters, techincal engineer and after-service more than 100 people.Also products achieved CE,ISO9001:2008,ISO2001:1400 etc. certificats.And passed many patents.
4. Our products are well received by our customers in Spain, Italy, Canada, Venezuela, Austraila, Thailand, Malaysia,Philippine,Indonesia,and with some Africa countries etc.
5. we have many cooperation companies :like dehydration equipment,desulfurization equipment,gasified equipment,recovery system exhaust heat,CCHP system etc.So can offer you complete project proposal if you like.

cummins diesel generator certificates and Service:
1.pre-sale service:
We will send our engineer to prospect the site of power station free to charge.According to the situation of site we can supply you many drawings which can meet the requirement of design and construction,like power station floor plan,engineering flow sheet of circle cooling system,genset installation,genset foundation,electrical connection and some other techincal support etc.
2.Sale service:
we will send our engineer to the site to guide you the installation of generator set, subsystem and relative equipment.We will debug the generator set till it can generate power successfully.We will also supply a technical training to the operators.You also can send your staff to our company.We can train you till you can operate the generator set and during this time we can offer you board and lodging free of Charge.
3.After-sale service:
(1)in our company, different people is in charge of different area,we will response periodically and support you technical service free of charge,include equipment debugging,fault eliminating,technical advice,maintenance assistant,etc.
(2)For the quality problem, we will service for you free of charge during the guarantee period.
(3)One year guarantee period and lifetime service.
(4)Insisting on principle of "solving problems first,trying to recover the generator set as soon as possible and then analysis the reason",we solve quality problem in time when genset doesn't work,We insure to help our clients to gain the biggest economic profit.

Any more details need to know please feel free to asked.

AC Alternator Silent Diesel Generators


Dayang product no.

LN200GF


Prime

standby

Generator set power(KW)

160

180

Generator set power(KVA)

200

225

Engine power(KW)

183

201

Engine model

TAD722GE

Engine manufacturer

jinan lvneng

Engine type

In-line,6 cylinder,4-stroke,turbocharged

Engine cooling mode

Design as a whole under 40 water tank radiator,
belt-driven cooling fan and safety shield

Speed regulation system

Heinzman mechanical governor, EDC4 electronic valve speed control system

Start-up mode

24V DC start up, equipped with silicon rectification charging alternator

Filter system

Dry air filterDual-fuel filter, oil filter,coolcant filter,


Fuel system

Bosch monomer for fuel pump

Engine exhaust L

7.15

Compression ratio

18.1:1

Bore x stroke (mm)

108X130

Coolant capacity L

37.1

Alternator

Synchronous brushless alternator(available)

Short circuit defend

Air switch

Rated voltage /frequency/power factor

400V/230V,50Hz,0.8lagging,three-phase four wires

Stable frequency charge ratio

Better than 4%

Idle voltage regulation scope

≥ 95%~105%

Stable voltage regulation ratio

Better than ± 1%

Insulation grade /defend grade

Grade H/IP22

Telephone influence factor(TIF) /Telephone harmonic-wave factor(THF)

TIF<50/ THF<2%

Bundled parts

Fuel tank ;plumbic acid high-energy batteryexhaust siphonsylphon bellowsflangemuffleranti-crash mat

Overall dimension mm

2550x880x1400

Generator set weight kg

1480



3. Other Specification



Color
your choice
CertificatesISO 9001:2008
Warranty1 year or 1000 running hours
TypeOpen
Control SystemAutomatic alarm system



Prod Model: LN300GF
Markets: Southeast Asia,Africa,Mid East,Eastern Asia
Rated Power: 300kw
Standby Power: 240kw
Protection Class: IP23
Control Panel: Digital Panel
Rated Voltage: 400/230V
Frequency: 50/60Hz
Regulator: AVR
Model Number: Ln-.300gf
Brand: Lvneng
Generator: Choice
Type: Self-Starting Diesel Generator
Installation Method: Fixed
Stroke: Four Stroke
Cooling Method: Water Cooling
Output Type: AC Three Phase
JiNan LVNENG POWER MACHINERY EQUIPMENT Co., Ltd was founded in July, 2009. It's located in high-tech development zone in the east of Jinan city with advantageous geographical position and good transport facilities The Company owns two factory regions research and production, with more than 150 staffs in company. And twenty of them are high-level technical talented person We own developed production line, impeccable quality test system and professional sale and service-after-sell team, and our company is committed to research production marketing and after-sale service of synthesis firm. With our excellent quality product and perfect after-sale service, we won praises and approbation from our customers.

Our products include 105, 135 and 190 series base engines. The output power ranges from 10kw to 500kw. And our main products are kinds of diesel engines, diesel generator and fuel gas generator, including natural gas generator methane gas generator straw gas generator biomass gas generator sets coal gas generator, coke oven gas generator sets, Mobile power station(Mobile trailer series), Static-speaker unit, Diesel engine and diesel generator sets etc.

We manage our company by ISO9001 system strictly. Gas engines and alternators are environment-friendly products.

All large, medium and small power products can be produced and the power performance, economical efficiency and reliability are all in the advanced level of this field, with the improvement of R & D department, Our Company install the valve seal and exhaust temperature meter for the products which are out form company, really save fuel consumption/automatic temperature control. For the vast number of users to save a lot of cost, has been widely praised by users

JiNan LVNENG POWER MACHINERY EQUIPMENT CO, . Ltd persist in scientific and technological innovation manage Innovation development direction Always insist on customer-first Business ideas of Mutual benefit, insist on Energy saving and environmental protection Safe and reliable quality policy Insist on fast\Exquisite Standard Service tenet. Inherit" Quality is the first, credit as prerequisite" as Core concept, constantly creating greater value for customers, Promoting sustained and healthy development of the company

"LVNENG, Dedication power \Pursuit excellence" A broad application market, quality products, quality and service will be our cooperation to build a good platform. Join hands with LVNENG success-together. Looking forward to Look forward to working with you.
