5KW Wind Generator System
Product Name: Max generating capacity/day Min generating capacity/day Average generating/day
Wind generator 50KW 55KWX3H=165KW 50KWX6H=300KW 465KW
50KW Wind Generator System Configuration
Name Specification Quantity Note
Wind generator 50KW/380V 1 unit Vertical axis turbine, low speed 32-pole three-phase permanent magnet generator, gearbox
Standard colloid accumulator battery 12V A group 300/B group 12V200AH A group 250/B group 45pieces Design using life 10-12year
The integration of three-phase sine wave inverter control DC500V/AC380V/60kw 1 piece Life 20-25years
Smart AC/DC distribution box 60KW 1 unit DC1 Way/ AC 1Way output
Lightning box 1 unit C/D grade 60-80KA
Battery bracket
Load bearing 2500KG
2 units Square rod bracket
Battery cables 25MM2 80m
Wind generator cables 3X352 100m
Wind generator control cables 6X1.52 100m
Battery copper fittings 200A 300 pieces
Fastening bolts Adaptation
Construction and installation accessories Adaptation
System features: According to local weather conditions(for wind resources sufficient occasions)the average daily generation capacity is 465KW, Max power 409KW.
Warranty: 1year, provide construction manual by loading. (not includes the tower)
Small and medium-type wind turbine grid system solutions
The wind power station wind environmental conditions:
General requirements for the annual average wind speed of 3m / s or more, the annual 3-20m / s, the effective wind speed cumulative number of hours 3000h above.
Reference Platform:
(No need of using your sate electricity) wind power systems, power changes DC electricity by MPPT, then to charge the battery. Battery provides DC electriciy to MPPT. MPPT changes the DC electricity into AC electricity, provides power to the electricity load. Therefore, the stand-alone wind power system includes wind generator systems, MPPT and battery system.
Configuration:
50KW wind turbine: N pieces
Total capacity: N * 50KW
Tower: N sets
Control MPPT: N sets
Battery: N units
Supporting cables and materials: N sets
Installation and test cost: N USD.
Reference Platform NO. 2:
How to incorporate into the local power grid, the NO. 2 program can save a lot of cost of investment.
50KW wind turbine: N pieces
Total capacity: N * 50KW
Tower: N sets
Transformers: N sets
Rectifier: N sets
Supporting cables and materials: N sets
Installation and test cost: N USD.
Generating capacity is calculated as follows:
2000-3000 hours per year greater than 3 m / sec according to the local wind resource, power generation time of wind generator according to the time value is estimated at 2200 hours. Wind turbines in the wind conditions would not have been full-load power, the power rating of 30% of the conservative calculation. Generating capacity of this program should be: N × 50 × 2200 × 0.3 = N × 33000Kwh.
Calculated in accordance with industrial electricity prices X yuan / kWh, the annual direct benefits of X × N × 33000. Wind generator design life is 20 years, overall revenue: 20 × X × N × 33000.
Small and medium-type wind power generator system main components:
N pieces small and medium-type wind turbines connects together, they can make of certain high-capacity power supply, have formed themselves into a unit to the grid by grid-connected inverter in a wind turbine single and a single square wave 50Hz. Connect a reator into the grid from Three-phase AC output termination, it can be trimmed away harmonic, and it can automatically control the power grid and wind turbine energy reasonable match.
| (Total power): | 5kw |
| (blade diameter): | 3m |
| (blade high): | 5.0m |
| (r/min): | 45 |
| (rated speed): | 13m/s |
| (rated power): | 5kw |
| (max power): | 6.5kw |
| (output voltage): | AC220V |
| (start up wind speed): | 1.8(m/s) |
| (work speed): | 2.5(m/s) |
| (security wind speed): | 45(m/s) |
| (high of tower): | ≥8(m) |
| (top quality except tower): | 600kg |
| (tower type): | Customized |
| (output controller system | Automatic |
