VGB5-2: "AA-Size" Vibration-powered Generator
"The AA-Size" vibration power generator, the shape and size is same as battery AA size, that designed to replace chemical battery AA size in some device with low power consume. For example, the TV remote control
: Same as battery AA size
: Be set inside a remote control to replace chemical batteries AA size
: Shaking up to power generation
: Shaking up at any time to generate power when using
: Can be used for long time; Without be replaced
: No leakage phenomenon, Not corrosion
: To replace chemical batteries; To protect environment
: Frequency around: 4-10Hz;
: Shaking frequency like shaking a caster
: The voltage is about 2.6-2.8V when shaking 5-10 seconds;
: Shaking more quickly, generating more power
: The same working life with remote control
Common Battery Vibration Power Generator
Voltage 1.25V -2.8V (1-2 PCS) 2.8V - 3.0V (1 pair)
Working Life 6 - 9 months 6 years above
Replace To be replaced when exhausted Without be replaced, use for a long time
Leakage and corrosion Yes No
Power Chemical reaction Physical transformation
Dimension AA: D: 14mm; H: 48mm AA: D: 14mm; H: 48mm
The vibration power generator will replace batteries AA size and contribute to reducing the amount of waste of chemical battery AA size. It ensures the versatility of the generator by employing the shapes of commonly-used batteries. When used with a low power consumption device such as a remote, the generator can replace a pair of batteries.
Specifically, the generator can be used for a device that does not always consume electricity and has a power consumption of about 40mW, For example, the power consumption of a normal remote is less than 40mW.
We focus on green energy; The mini vibration power generator. All products have independent intellectual property rights.
