DC Generator (Diesel, Silent Type)
1. HD6500DSL shall have inbuilt micro-processor based Controller unit to control the DC-GENERATOR operation.
2. HD6500DSL shall have RS-485 port connectivity with external systems.
3. HD6500DSL shall have Weather Proof Canopy suitable for outdoor operation
4. HD6500DSL Internal Battery 12V/60AH
5. HD6500DSL shall have current limit control to prevent overloading of the machine. In case of any sudden load Current rise, HD6500DSL will go into constant current mode beyond the set load current.
6. HD6500DSL shall have battery charging current sensor to control the rate and extent of battery charging.
HD6500DSL shall not allow battery charging to go beyond the rate of battery charging. In case battery has been charged more than desired limit then HD6500DSL will switch OFF.
7. HD6500DSL shall have remote Start/ Stop functionality to help automation of the operation. It shall have Auto as well as Manual Start/ Stop facility.
8. HD6500DSL LCD Display & Key Pad
A. HD6500DSL shall have LCD display for showing the DG operation Parameters.
B. LCD display shall show the configuration parameters set on the DG.
C. Display shall show the status of the DG.
D. DG controller shall have soft touch keys to set the configuration and to select the desired parameter for verification.
9. HD6500DSL shall have MCCB protection on output voltage for disconnection and protection purpose.
10. HD6500DSL shall monitor below mentioned operational parameters. The operational parameters shall be extendable to Power Interface Unit for remote monitoring.
Remote Start / Stop
DC-generator Voltage (Volts)
Load on HD6500DSL (Amp)
Battery Current & Voltage
Cumulative HD6500DSL Running Hrs
11. HD6500DSL shall provide below mentioned Alarms for extension at the BTS site.
HD6500DSL ON
HD6500DSL Fail to Start
HD6500DSL Fail to Stop
HD6500DSL Fault (Alt fault, low rpm, high rpm, Air filter choke)
Engine High Temperature
Low Fuel level
Low Lube Oil Pressure
12. HD6500DSL shall have following additional safety features: Emergency Stop\ Short Circuit \Under speed/ over speed
13. HD6500DSL shall be suitable to operate in outdoor from -5 to 50 Deg ambient temperatures without any external heating or cooling mechanism. "
14. HD6500DSL shall have high quality Anti Vibration mounts for Engine to prevent any external visible vibration of the canopy in running condition.
DC Diesel Generator Set
|
DC-Generator |
MODEL |
HD6500DSL |
|
Type |
Permanent magnet, brushless, bearing-less |
|
Voltage Regulate |
Automatism electronic regulate |
|
Rated Dc Output |
5.5KW |
|
Max Dc Output |
6.0KW |
|
Voltage output regulation |
0.5-1.0VDC |
|
Ripple quotiety |
150mV |
|
Rated Current |
115A |
|
Rated Dc Voltage |
48V |
|
Run output Dc Voltage |
52.5V |
|
AC-Generator |
Voltage Regulate |
Automatism electronic regulate |
|
Rated Ac Output |
5.5KW |
|
Max Ac Output |
6.5KW |
|
Frequency |
60/50Hz |
|
Rated Ac Voltage |
120 or 220V |
|
DC-Generator-Set |
Fuel |
0# (summer) -10# (winter) Diesel oil |
|
Starting system |
Electric start |
|
Noise level |
68-70(7m)dB(A) |
|
Oil alarm |
No lube oil Auto stop safekeeping |
|
continuous operating |
8h |
|
Fuel capacity |
customer optional |
|
Front panel control system |
LCD control panel. |
|
Dimension L× W× H |
1250× 750× 860mm |
|
weight |
150kg |
