| Price: | US $ 5500-5700/Piece |
|---|---|
| Trade Terms: | FOB,CFR,CIF |
| Min Order: | 1/Piece |
| Pay Type: | L/C,T/T,Paypal,Western Union |
(1) The warranty period is start from the date of shipment which show on the bill of loading or air waybill.
(2) Free maintenance services during the warranty period the cost involved be borne by the company, do not charge a fee to customers, free warranty if any damage outside the warranty period, the company will charge a fee for labor costs and materials.
(3) the warranty period, company's quality problems caused by the maintenance of the freight borne by the company, if not under warranty or man-made damage, the freight charges by the customer.
| Model | 3KW-100 | 3KW-180 | 5KW-100 | 5KW-150 | 10KW-100 |
| Rated Power | 3KW | 3KW | 5KW | 6KW | 10KW |
| Rated Rotate Speed | 100RPM | 180RPM | 100RPM | 150RPM | 100RPM |
| Rated Voltage | 380VAC | 380VAC | 380VAC | 380VAC | 400VAC |
| Rated Current | 4.6 | 4.7 | 7.6 | 15.2 | 14.5 |
| Efficiency | >85% | >85% | >88% | >88% | >88% |
| Wending Method | Y | Y | Y | Y | Y |
| Insulating Resistance | 100Mohm Min(500V DC) | 100Mohm Min(500V DC) | 100Mohm Min(500V DC) | 100Mohm Min(500V DC) | 100Mohm Min(501V DC) |
| Leakage Level | <5 ma | <5 ma | <5 ma | <5 ma | <5 ma |
| Start Torque | <1 N/M | <0.5 N/M | <0.5 N/M | <1 N/M | <1N/M |
| Phase Type | 3 Phase | 3 Phase | 3 Phase | 3 Phase | 3 Phase |
| Structure | Out rotor | Out rotor | Out rotor | Out rotor | Out rotor |
| Stator | Coreless wire coil | Coreless wire coil | Coreless wire coil | Coreless wire coil | Coreless wire coil |
| Rotor | Rare Earth Permanent Magnet | Rare Earth Permanent Magnet | Rare Earth Permanent Magnet | Rare Earth Permanent Magnet | Rare Earth Permanent Magnet |
| Generator Shell Diameter | 620 | 550 | 700 | 620 | 770 |
| Generator Shell Length | 410 | 330 | 400 | 410 | 590 |
| Weight | 110 | 65 | 125 | 110 | 245 |
| Shaft drameter | 80 | 78 | 98 | 80 | 85 |
| Generator shell material | Aluminum alloy | Aluminum alloy | Aluminum alloy | Aluminum alloy | Aluminum alloy |
| Shaft material | Carbon steel | Carbon steel | Carbon steel | Carbon steel | Carbon steel |
| Bearing | Deep groove ball bearing | Deep groove ball bearing | Deep groove ball bearing | Deep groove ball bearing | Deep groove ball bearing |
| Prod Model: | GDG |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Axis Type: | Vertical |
| Type: | Coreless |
