| Price: | US $ 13000/Set |
|---|---|
| Trade Terms: | FOB,CFR,CIF |
| Min Order: | 1/Set |
| Pay Type: | L/C,T/T,D/P,Paypal |
|
The main parameters of the set |
|
|
The model of the unit: |
64GF |
|
Prime power: |
80KVA |
|
Rated voltage: |
220V |
|
Rated current: |
115.2A |
|
Rated frequency: |
50Hz |
|
The factor of rated power |
COS=0.8lagging |
|
The regulating rate of steady voltage: |
≤ 1% |
|
The regulating rate of instantaneous voltage: |
-15%~ +20% |
|
The time of steady voltage: |
≤ 1.5sec |
|
The waving rate of voltage: |
≤ 1.0% |
|
The regulating rate of steady frequency: |
≤ 3% |
|
The regulating rate of instantaneous frequency: |
≤ ± 10% |
|
The time of steady frequency: |
3sec |
|
The waving rate of frequency: |
≤ 1% |
|
Displacement (L): |
5.9 |
|
The waste of fuel with full load: |
≤ 210g/kwh |
|
Lube-oil consumption (L): |
16.4 |
|
The main parameters of the diesel engine |
|
|
Brand: |
CUMMINS |
|
Model: |
6BT5.9-G2 |
|
Type: |
four strokes, waste gas turbine boost, direct spurting type |
|
Cylinder: |
4 cylinders |
|
Cooling way: |
water cooling |
|
Rotating speed: |
1500r/min |
|
The regulation of rotating speed: |
Electrical speed regulator |
|
Starting way: |
DC24V\ starting with electricity |
|
The main parameters of the generator |
|
|
Brand: |
Kaijieli(China-French joint venture Leory Somer technology) |
|
Model: |
TWG2F |
|
Type: |
Brushless, Self-excite, AVR automatic voltage regulating |
|
The connecting way of the phase: |
three phases four lines |
|
Insulation degree: |
H degree |
|
Enclosure degree: |
IP21-IP23 |
| Prod Model: | KH-64GF |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Size (Mm): | 2200*800*1300 |
| Weight (Kg): | 1180 |
| Cooling Method: | Water Cooling |
| Stroke: | Four Stroke |
| Installation Method: | Fixed |
| Type: | Self-Starting Diesel Generator |
| Output Type: | AC Three Phase |
