Home Generator Products 60kw, 30rpm Permanent Magnet Generator/Alternator

60kw, 30rpm Permanent Magnet Generator/Alternator

60kw, 30rpm Permanent Magnet Generator/Alternator
Price: Negotiable/Set
Trade Terms: FOB,CFR,CIF
Min Order: 1/Set
Pay Type: L/C,T/T,Paypal,Western Union
Low speed permanent magnet water generator, leaving out speed-up machine, generating 50 Hz Power at low speed. 60Hz also available

High efficient PM rotor, compact structure. No carbon brushes, do not need excitation, no spark, no excitation winding, high rotor intensity, no field control box, sample construction, high performance.

Protection class: IP44, avoid water, mud, dusty getting into the motor, long life, especially suitable for outdoor requirements.

No excitation control-box, sample construct, high performance.

Motors is running efficiently throughout the entire speed range, saving energy.

Using embedded rare-earth magnetic steel, especially suitable for turbulence, impact dynamic and reverse running.

The motor adopts wind-cooling or water-cooling, low temperature, adopts high speed oil-retaining bearing, maintenance-free, high reliability, long life-span.

You can change the motor voltage, speed, Power and other parameters, the out size of the motor can be also changed. You can use splined shaft, dual shaft, flange and other output styles
PowerAC voltagespeedpolesRated torquecurrentefficiencyweight
60 kw400V30pm4819100Nm93A93.8%3900kg
300 kw400V300rpm249550Nm460A93.8%3900kg
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Axis Type: Horizontal
Phase: 3 Phase
Certification: CE, ISO
Rotating Shaft: Horizontal
Stress Way Of Blade: Resistance
Power: 10-100kW
Number Of Blade: Three Blade
Willgain Power Industry Co., Limited is specialized in manufacturing and supplying wind turbine and generatering system since 2008. We mainly supply horizontal/vertical axis wind turbine from 300W-500kw, horizontal/vertical permanent magnet generator from 300W-1000kw with various speed based on customer's requirements and Francis/Kaplan type hydro turbine system below and over 50kw.

Our partner manufacturers are committed to continuously improving our operations and meeting the needs of our customers through innovation and new product development. We work closely with them to optimize the performance and cost-effectiveness of their processes.
