Rated frequency (Hz) 50 60
Rated voltage (V) 230 240/120
Rated current (A) 21.7 22.9/45.8
Rated output power (KVA) 5.0 5.5
Rated rotation speed (rpm ) 3000 3600
DC output 12V-8.3A
Power factor cosφ 1.0
Phase number Single phase
Excitation mode AVR
Noise level dB (A)/7m (zero load ~full load ) 75~79
Overall dimension [mm (in)] (LxWxH ) 720x492x650(28.35x19.37x25.59)
Dry weight [kg (lbs)] 95(209)
Structure model Open-frame
Connection mode Transmission shaft rigid coupling
Engine model SD186F
Engine type Single cylinder, 4-stroke, air-cooled, direct injection, diesel engine
Displacement [cm3 (cu-in)] 418
Compression ratio 19: 1
Rated power [kW (HP)/rpm] 6.3(8.6)/3600
Rated rotation speed (rpm)
T. C. I with
Spark plug ----
Starting system Recoil starter /Eletrical Start
Rotation direction (view from wheel) Clockwise
Fuel type 0# (summer), -10# (winter) light diesel oil
Lube brand SAE10W30(above CC grade)
Low oil pressure alarm system With.
GuangZhou YueChai Electrical & Mechanical Co., Ltd., is located in the third biggest city-GuangZhou in China and now has been one of the fastest developed generator sets manufacturer. We specialize in production, sales and after-sales service of power supply system (Diesel Generator Sets, Gasoline Generator Sets and Solar power system).
After long time development now we have many sales centres and offices throughout southern China. With large sales net we have good customer service experience with different natinality people and update marketing information.
Quality is always the most concerned factor in our company. We have high-performing quality control system and have been certificated by ISO9001/CE. Under the quality control system the performance of our generator can be guaranteed. We also possess excellent Research & Development department of generator sets to improve our product competition.
We currently have long time strategic partnership with many worlds' famous engine company such as Cummins, Perkins and Yuchai. Our gnenerators sell all over the world including Southeast Asia, Middle East, Africa, Europe and USA markets.
Superior quality and customer satisfaction are always our pursuit, honesty first is essential in our business. We hope to establish long time business relationship with people all over the world.
