Model name: FD5-5kw & FD6-5kw
Horizontal axis, 3 blades, PMG, AC 3 phrases
Blades diameters: 5m or 6m
Rated working wind speed: 12m/s(6m blades diameters is 10m/s)
Start up working speed: 3m/s
Working wind speed: 3m/s-30m/s
Survival wind speed: 50m/s
Working voltage: DC48V, DC240V, DC300V or special request
Rated output power: 5kw
Max output power: 7kw
Tower type: Tilting up tower/guy wire tower/independence tower
Tower height: 8m, 12m, 15m (can be requested accordingly, also can be provided by youself)
Working system: Off-grid working system
On Grid connection working system, if you only take wind turbine from us, we will provide the generator actual test data for your inverter.
For more details about our wind turbine, pls contract with us!
Ningjin huaya industry Co., Ltd. is specialized manufacture of small wind turbine generator.
Form the first 50W, 100W wind turbine to 300W-20kw wind turbine, we past 15 years. Now we have the steady off-grid working system, 1kw, 2kw, 3kw, 5kw, 10kw, 20kw on-grid working system. To provide the steady system is our aim.
Blades:
The blade form is chosen by wind tunnel test. The aerofoil with the highest wind speed utilization ratio is used. The wind energy transfer efficiency can reach 0.42.
Generator:
ND-fe-b permanent magnet. Packaged type tangential grinder magnetic circuit rotor; High magnetic flux density, small cubage, good manufacturing technics and high capability.
Adopt Sweden SKF bearing.
Close transmission slip ring, the cable will not enlace
Tower:
Tower with guy wires, tilting up tower, hydraulic tower, independence tower. It can be designed according to your request.
Now the wind turbine system is working in more than 30 countries. To provide the good, steady system is our aim.
For more products details, pls contract with us! We will provide you quickly and professional feedback.
