5KVA/ 6KVA Silent Type Diesel Generator with ATS Optional Detail DescrIption Super Silent Type Diesel GeneratorPower Output: 4kVA, 5kVA, 6kVA, 7kVA, 8kVA Optional
Silent Cart Type / Open type is optional
High Quality Muffler / Silencer with low noise
Start System: Electric Start with Battery
Single Phase / Three-Phase is Optional
ATS (Auto Transfer System) is Optional
with CE Certificates
Skilled Technicians and Professional Engineers
Products Photos
Technical data | NAME | ITEM | AD5800DSE-A | AD6800DSE-A | AD5800DSE-B | AD6800DSE-B |
| Generator | Type | Silent Type |
| Revolving Magnetic Field, Self-exciting, 2 Poles, Single-phase (or 3-phase) |
| Rated Frequency(HZ) | 50/60 |
| Rated AC Output(KW) | 4.2/4.6 | 5.0/5.5 | 4.2/4.6 | 5.0/5.5 |
| Max.AC Output(KW) | 4.6/5.0 | 5.5/6.0 | 4.6/5.0 | 5.5/6.0 |
| Voltage(V) | 110,115,120;220,230,240;110/220,115/230,120/240,(Single Phase)380,400,380/220,400/230(3-Phase) |
| Voltage Regulator | Auto Regulating System |
| Power Factor | 1.0 (Single Phase) 0.8(Three Phase) |
| Engine | Model | DV186 | DV186A | DV186 | DV186A |
| Type | Air-cooled, Single-Cylinder, 4-stroke, Direct-injection, Diesel Engine |
| Bore×Stroke(mm) | 86×70 | 86×72 | 86×70 | 86×72 |
| Displacement(cc) | 406 | 418 | 406 | 418 |
| Max Power | 9.4/3600 | 10.0/3600 | 9.4/3600 | 10.0/3600 |
| Recommendad Fuel | Light Diesel |
| Fuel tank capacity(L) | 12.5 |
| Engine Oil capacity(L) | 1.65 | 1.65 | 1.65 | 1.65 |
| Lube Oil | SAE 10-30W |
| Start System | Electric Start |
| Set | Operating Hour for 1Tank Fuel(Hrs) | 11 | 9 | 11 | 9 |
| Noise level(7m)dB(A) | 82-84 |
| Packing Dimension(L×W×H)mm | 755×490×605 | 955×565×780 | 955×565×780 | 955×565×780 |
| Gross Weight/Net weight(kg) | 92/90 | 175/170 | 170/165 | 175/170 |
About us
TAIZHOU LONGFA MACHINERY CO., LTD
Located: Taizhou City, Zhejiang Province, China
Main Business: Generator, Water Pump & Engine
History: 12 years experience for manufacturing
Marketing network: Europe, Middle East, Africa, South East Asia, etc
Certificate: CCC, CE, ISO9001, SONCAP, EPA
Guaranty: 12 months warranty for all products
Technology: Professional technical engineers and R&D team
Management: Scientific management and strict quality control system
Equipments: Advanced automatic production line and test equipment
Innovation: Continuously diversify products range to satisfy customers
Production capacity: 50000PCS/month
Marketing mode: 100% export business
