| Price: | US $ 4868/Piece |
|---|---|
| Trade Terms: | FOB |
| Min Order: | 1/Piece |
| Pay Type: | L/C,T/T,Western Union |
Genset general feature:
|
1.Generator can be used as Main industrial generator
2.CCS,BV, CE, ISO9001:2008 approved
3. Water Cooled by radiator
4. Adopt Yuchai Engine
5.Marathon single-shaft alternator standard , Stamford/Sunvim/Siemens/Megaton alternator is optional
6.Parallel connection: Two and more normal industrial generating sets can transfer loading without stoping ,
and can realize parallel.
7.Standard SAE coupling the engine and alternator
8.With efficiency anti-vibration devices
9.Cold rolled steel one time molded base
10.High reliability , low use and maintenance cost
1.Main technical data of gensets
| ||
1.1 | Model | HQY50GF |
1.2 | Prime power | 50KW |
1.3 | Prime voltage | 230/400V |
1.4 | Speed | 1500 rpm |
1.5 | Weight | 1050 kg |
1.6 | Overall dimension | 1850*750*1250 mm (just for reference) |
2.Main technical data of engine | ||
Yuchai engine, 4 stroke. DC start. Come with sea water pump, heater exchanger and expansion water tank, open-cycle cooling. | ||
2.1 | Brand | Yuchai |
2.2 | Model | YC4D85Z-D20 |
2.3 | Governor type | Electronic |
2.4 | Configuration | 4 cycle , 4 cylinder in line |
2.5 | Cooling method | water cooled by radiator |
2.6 | Bore/Stroke | 108*115 mm |
2.7 | Aspiration | Turbocharged / After cooled |
2.8 | Starting method | electronic |
2.9 | Fuel consumption | 200g/kw.h |
3. Main technical data of alternator | ||
Alternator is selected the new type brushless alternator designed by US Marathon Electric, which has a unique design, advanced structure, small size, light weight, excellent performance, reliable running and easy-to-use operation. | ||
3.1 | Brand | MARATHON |
3.2 | Model |
GM-50-4
|
3.3 | Prime power | 50KW |
3.4 | Configuration | Brushless , self-exciting |
3.5 | Prime voltage | 230V/400V |
3.6 | Frequency | 50 HZ |
3.7 | Power factor | 0.8(lagging) |
3.8 | Phase/wire | 3 phase 4 wires |
3.9 | Isolation | H |
3.10 | Protection grade | IP23 |
| Prod Model: | power generator |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Brand Name: | Yuchai |
| Rated Current: | 90A |
| Weight: | 850kg |
| Size: | 1900*660*1050mm |
| Cooling System: | Water Cooled |
| Control Mode: | Auto / Manul |
| Silent Level: | 60db-85db |
| Base Fuel Tank: | 8-12 Hour Fuel Tank |
| Quality Control: | ISO14001 |
| Warranty: | One Year or 1000 Hours |
| Stroke: | Four Stroke |
| Type: | Basic Diesel Generator |
| Cooling Method: | Water Cooling |
| Installation Method: | Fixed |
| Output Type: | AC Three Phase |
