Lower rated wind speed
Steady working system
Factory sales directly
Professional tech support
Ce iso ccc
50kw wind turbine normal data:
Item FD17-50KW
Blades rotor diameter(m) 17
Blades material Reinfore FRB
Blades number 3 pcs
Rated wind speed (m/s) 12
Start up wind speed(m/s) 3
Working wind speed(m/s) 3.0-35
Survival wind speed(m/s) 50
Start up torque(n/m) 100
Speed regulation method Pitch control + initiative yaw
Stopping method propeller feathering, yaw, electromagnetic braking
Generator type 3 phrase AC permanent magnet generator
Rated working voltage 360-700VDC
Rated output power 50KW
Max output power 60KW
Rated rotation speed (rpm) 60
Wind turbine main body weight(kg) 4200
Tower weight 20(kg) 5000
__________________________________________
Note:
1. Stand alone tower, hybraulic tower
2. Working voltage can be special requested;
3. Ce, ccc, iso approved;
4.23m blades rotor for low wind speed place, optional
5. On grid working system
For output power curve, pls contact with us!
www.huayaturbine.com
Ningjin huaya industry Co., Ltd. is specialized manufacture of small wind turbine generator.
Form the first 50W, 100W wind turbine to 300W-20kw wind turbine, we past 15 years. Now we have the steady off-grid working system, 1kw, 2kw, 3kw, 5kw, 10kw, 20kw on-grid working system. To provide the steady system is our aim.
Blades:
The blade form is chosen by wind tunnel test. The aerofoil with the highest wind speed utilization ratio is used. The wind energy transfer efficiency can reach 0.42.
Generator:
ND-fe-b permanent magnet. Packaged type tangential grinder magnetic circuit rotor; High magnetic flux density, small cubage, good manufacturing technics and high capability.
Adopt Sweden SKF bearing.
Close transmission slip ring, the cable will not enlace
Tower:
Tower with guy wires, tilting up tower, hydraulic tower, independence tower. It can be designed according to your request.
Now the wind turbine system is working in more than 30 countries. To provide the good, steady system is our aim.
For more products details, pls contract with us! We will provide you quickly and professional feedback.
