Blades peculiarity
High efficiency FRP material, ultraviolet prevention rosin, plus unidirectional high strength glass fiber, modernization craft vacuum cast technique synthesis.
Controller and inverter Integrated system design.
Off-grid control: Real-time wind speed testing, wind direction testing, rotation speed testing. V. A. P testing generator temperature & twist testing etc, automatical PLC human management without manual intervention, wind generator run more smoothly.
On-grid control. Intelligent PLC control, automatic cut-in and cut-out. Reactive power compensation. Constant speed and voltage. No power or overload shutdown automatically.
Inverter. Powerful self-protection function., over voltage, under voltage automatic off. Output short circuit protection. Pure sine wave. Constant voltage output.
Dogvane: Measurement of wind turbine angle agaist the wind
Anemoscope: Testing real-time wind speed and then transfer the signal to controller
Model |
VPFD18.0-50000W |
Type of generator |
Direct drive permanent magnet (PM) generator |
Blade diameter |
18.0m |
Blade Material: |
FRP (Fiber glass reinforced*3)
Blades Pitch Control |
rated rotor speed |
60r/min |
Controllerer |
Controller based PLC module |
automatic adjustment system |
Automatic lubrication; Automatic variable pitch; Automatic control |
rated speed |
10m/s |
rated Power |
50000W |
max Power |
55000w |
output voltage |
DC380V/AC380V/50HZ |
start up wind speed |
3(m/s) |
work speed |
3-20(m/s) |
security wind speed |
40(m/s) |
Rate-limiting mode |
Hydraulic brakes, PLC control
Mechanical brake
Electromagnetic brakes / air brakes
Electric yaw system |
Dogvane |
Measurement of wind turbine angle agaist wind |
Anemoscope |
Testing real-time wind speed and then transfer the signal to controller |
height of Free sdand tower |
18m(hot galvanized and plastic spraying) |
top quality except tower |
2050kg |
Total weight(kg) |
7800kg |
output controller system |
Controller, Inverter |
Suggested batteries and it' s capacity |
12V 200AH 120psc
(120PCS 12V200AH) |
can supply power for |
SmallVillage, air-condition, refrigerator, washing machine, water pump, electric pan, color TV, lighter, fanner, charger |
We specialize in this field for several years, with the strength of wind turbines, with good quality and pretty competitive price. SHANDONG JIALI NEW ENERGY Co., Ltd founded in 1994, specialized in manufacturing wind turbines, the main products are 200W, 300W, 600W, 1KW, 2KW, 3KW, 5KW, 10KW, 20KW, 30KW, 50KW and 100KW wind turbines and small solar panels, wind solar hybrid systems. Products are exported to the United States, Germany, Britain, France, Pakistan, Indonesia, Mongolia, has a customers high praise.
