Home Generator Products 50kw Gas Generator Set /6kw-500kw Gas Gensets

50kw Gas Generator Set /6kw-500kw Gas Gensets

50kw Gas Generator Set /6kw-500kw Gas Gensets
Price: Negotiable/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 1/Piece
Pay Type: T/T
Gas type: Natural gas, biogas, CBM etc. Gas Generator Set Features: Gas requirement 1. There should not contain liquid water or particulate matter(impurity <5um) 2. Gas calorific value ≥ 5000kca1/1, genset power will reduce when calorific value <5000kca1/1. 3. Sulfide content not more than 250mg/m³ , Gas should be desulfided when sulfide content surpass fixed content. (marks: Engine will be easy to be destroied when sulfide content goes too high. Gas generator set features: 1. Electronic air/gas mixer, which can supply best air fuel ratio to improve working efficiency and reduce Nox emision. Special regulation system is used to gas of mathane content above 30%. 2. Ignition system: High-precision Altronic ignition system imported from US prolongs engine's working life and improve the stability. 3. Long overhual period: 18000-25000 hours 4. Automatic smart control system, easy to handle. Duing the working time, genset processing automatic troubles testing. 5. Genset is approved by CE, ISO9001, 2008. The Electrical Performance of Diesel Generator Sets 1. Power factor: 0.8(lagging) 2. Connection way: Three phase four lines 3. Ambient temperature: -40degree~52degree 4. Steady voltage regulation rate: ± 1%; Transient voltage regulation rate: +20~-15% 5. Steady frequency regulation rate: ± 1%; Transient frequency regulation rate: +10~--7% 6. Voltage fluctuation rate: ≤ 0.5% 7. Frequency fluctuation rate: ≤ 0.5%
Gas Generator Parameters
Genset Model  15GF   24GF 30GF 40GF 50GF 75GF 90GF 100GF 120GF 150GF 200GF 400GF
Fuel Type Natural Gas, Biogas, CBM
Prime Powe9(kW) 15   24 30 40 50 75 90 100 120 150 200 400
Standby Power(kW) 16.5   26.4 33 44 55 82.5 99 110 132 165 220 440
Engine Model  493   4105 4105ID 6105 6105ID 6126 6126 6126 6126 6126 12V138 12V190
Manufacturer  Saffehanda   Saffehanda Saffehanda Saffehanda Saffehanda Saffehanda Saffehanda Saffehanda Saffehanda Saffehanda Saffehanda Saffehanda
Type  Naturally
Aspirated
  Naturally
Aspirated
Naturally
Aspirated
Naturally
Aspirated
Naturally
Aspirated
Naturally
Aspirated
Naturally
Aspirated
Turbocharged
intercooled
Turbocharged
intercooled
Turbocharged
intercooled
Naturally
Aspirated
Naturally
Aspirated
RPM  1500   1500 1500 1500 1500 1500 1500 1500 1500 1500 1500 1000
Number of cylinders 4   4 4 6 6 6 6 6 6 6 12 12
BorexStroke(mm) 93*102   105*125 105*135 105*125 105*135 126*130 126*155 126*130 126*130 126*155 138*150 190*210
Displacement(L) 2.771   4.33 4.68 6.49 7.01 9.7 11.6 9.7 9.7 11.6 26.9 71.4
Power of Engine(kW) 20   30 40 50 60 82 98.6 150 150 180 229 500
Fuel Consumption(m³ /kW@ h) 0.33   0.33 0.33 0.33 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3

Manufacturer  Saffehanda   Saffehanda Saffehanda Saffehanda Saffehanda Saffehanda Saffehanda Saffehanda Saffehanda Saffehanda Saffehanda Saffehanda
Power of Alternator(kW) 15   24 30 40 50 75 90 100 120 150 200 400
Rated Capacity(kVA) 18.75   30 37.5 50 62.5 93.75 112.5 125 150 187.5 250 500
Rated Voltage(V) 400   400 400 400 400 400 400 400 400 400 400 400
Rated Current(A) 27   43.2 54 72 90 135 162 180 216 270 360 720
Rated Frequency(HZ) 50   50 50 50 50 50 50 50 50 50 50 50
Power Factor (cosφ ) 0.8   0.8 0.8 0.8 0.8 0.8 0.8 0.8 0.8 0.8 0.8 0.8
Insulation Class  H   H H H H H H H H H H H
Degree of Protection IP21   IP21 IP21 IP21 IP21 IP21 IP21 IP21 IP21 IP21 IP21 IP21
Efficiency(%) 82.6   85.5 86.8 88.9 89 89.5 90.4 91 91.6 91.9 93 93.9

Steady Voltage Regulation(%) ± 1   ± 1 ± 1 ± 1 ± 1 ± 1 ± 1 ± 1 ± 1 ± 1 ± 1 ± 1
Steady Frequency Regulation(%) 1   1 1 1 1 1 1 1 1 1 1 1
Transient Voltage Regulation(%) +20~-15   +20~-15 +20~-15 +20~-15 +20~-15 +20~-15 +20~-15 +20~-15 +20~-15 +20~-15 +20~-15 +20~-15
Voltage Recovery Time(S) 4   4 4 4 4 4 4 4 4 4 4 4
Transient Frequency Regulation(%) -7~+10   -7~+10 -7~+10 -7~+10 -7~+10 -7~+10 -7~+10 -7~+10 -7~+10 -7~+10 -7~+10 -7~+10
Frequency Recovery Time(S) 3   3 3 3 3 3 3 3 3 3 3 3
Genset Size(mm) 1600*750*1200   1700*800*1300 1800*800*1300 2100*800*1300 2200*800*1300 2765*965*1500 2887*965*1789 2887*965*1789 2887*965*1789 2887*965*1789 3200*1400*1850 6000*1740*3000
Genset Weight(kg) 600   680 730 1000 1100 1200 2500 2500 2500 2500 3500 12600
Prod Model: 6KW-500KW
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Saffehanda Company is committed to diesel engines and power generating equipment research and development, production and sales. The leading products of our company are wind turbine(150W-1MW), gas generator set, R series and 495 series diesel engines, diesel generating sets, various complete sets of units and sparing parts etc. Which has a power scope of 2~2000KW, they are extensively used in generating equipments, agricultural machines, engineering machines, camion and boats or ships etc.

We are persisting in the principle of "benefits as the center, market as the direction, quality first and customers foremost". We will continue to innovate and reform in view of the trend of market and the requirement of clients. The company has a strict quality guarantee system and obtains ISO9001: 2000, ISO/TS16949: 2000 quality certificates, R series diesel engines are approved by Chinese CCS and ZY, EURO emission limits, Italian CE, American EPA and Indian CPCB certificates. There are 7 series products has been regarded as high-tech products in Shandong, 22 National patents have been applied, and be known as famous brand in Shandong. We have established the complete marketing network and sound service system. Our products are on sales throughout the whole country, moreover, have been exported to Asia, Africa, America, Europe etc, and have won universal praises from clients at home and abroad.

In recent years, we invested in the new 500-mu top-level casting and foundry center and assembly plant to combine the supply chain and upgrade production level from engine manufactory to the domestic leading diesel generators set supplier. The company developed steadily and was awarded as "high-tech enterprise", "Contract Abiding & Creditable Enterprise", "the 50 top industry enterprises" and the Grade A "Honest Taxpaying Company", "Shandong 100 Outstanding Machinery Industrial Enterprise", "Shandong Machinery Industry Civilization Enterprise", "Shandong 10 innovative Machinery Industrial Enterprise", "Technology-intensive and knowledge-intensive enterprises" etc.
