50Hz 350kVA /280kw Cummins Power Generator with Stamford Alternator

50Hz 350kVA /280kw Cummins Power Generator with Stamford Alternator
Price: US $ 28600-29300/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 1/Piece
Pay Type: L/C,T/T,D/P,Western Union
20kVA~250kVA Cummins Power Soundproof Generator with CE/Soncap Approval

Cummins Power Soundproof Generator is a set of complete equipment for electrical power supply. Cummins engines, high quality alternators and advanced full automatically control system are produced through strict test, which together provides reliable power no matter as standby, prime or continuous use.

Technical Specification for
Soundproof Generator:

Diesel Generator Parameter:
Power Factor: 0.8(lagging)
Protection Standard: IP21-IP23
Model of Connection: 3 phase 4 lines
Insulation Grade: H
Frequency Drop(%): ≤ 0.5
Transient state frequency deviation(%): (advertised power ) +10~-7
Frequency Recovery Time(S): ≤ 3
Voltage Recovery Time(S): ≤ 4
Waveform Distortion(%): ≤ 5

Frequency 50HZ, 1500RPM, Rating voltage 380V/220V, 400V/230V, 415V/240V

Diesel Generator Features:

1. High fuel efficiency: Fewer fuel consumption at leading level than other competitive products.

2. The turbocharger with waste gated design: Optimizes operation across the torque curve resulting in excellent low-end torque.

3. Compacted yet durable and dependable engine: Cummins engines contain up to 40% fewer parts than competitive engines in its class. This results in a better power-to-weight ration, a less chance of failure and lower repair cost.

4. Advanced design and manufacturing: Make the engine delivers superior performance and lower cost than competitive engines.

5. Excellent cold start performance: Optional assistant cold starter with improved 6.6KW starter and intake air heater.

6. Excellent performance and advantage: Adopt advanced design to achieve higher horsepower and lower weight.


7.Big enough free maintenance battery, world famous brand.

8.Packing with Strong and thick enough WOOD CASE to protect the gensets during long transporation.

9.Every spare parts suppliers are choosed extremely stricted, to control the quality well.

10.From engine to whole genset, we test every link of every product, and we also have test machinery and test center.

11.Many spare parts are produced by ourselves, could save cost for customers greatly.

12.We welcome every customer visiting our factory and test our products.

13.We have more than 20 engineers and technicians to provide reliable after sales service to all of our generator sets.


Quality:

Unite Power Cummins series diesel gensets offered by Unite Power Generation are manufactured strictly accord to the ISO9001:2000 international quality management system. Our company has commanded the design of diesel gensets well with the overseas companies' great support and the years' experience. Besides the design of industry workshop, our company also has good experience with the design for the monitors in intellectualized building, including connection, remote device,  engine room without on duty, soundproof design and installation. Up till now, there are thousands gensets with control monitor provided by Unite Power Generation, which proves the high preponderant situation of Unite Power Generation.

Service:
BEFORE SERVICE: According to the clients' requirement and actual situation, we will furnish the technology consultation and kinds of information.

AFTER SERVICE: Guarantee for one year or 1000 running hours (accord to whichever reach first) from arrival date of destination port. During the guarantee period, we will provide the free easy-damaged spare-parts for problems caused by our quality of production or raw material, except the damageable spare parts of diesel engine caused by customer's incorrect man-made operation. After expiration, our company provides cost spare-parts maintenance for gensets.


350KVA Silent Diesel Generator Powered by Cummins



1. Specification of genset
Gensets modelUPC350
Prime power350KVA/280KW
Rated Voltage380/220V
Rated frequency(HZ)50
Rated Speed1500rpm
Power Factor(COS)0.8(lagging)
Dimensions(mm) (L×W×H) -- silent type4120x1900x2400
Net Weight(kg)2650
Noise Level75 db(A) at 7 meters
2. Specification of diesel engine
Engine brandPowered by Cummins
Engine modelNTA855-G2A
Number of Cylinders6
Cylinder arrangementVertical in-line
CycleFour stroke
AspirationTurbo Charged
Bore×Stroke (mm×mm)140×152
Displacement (Liter)14
Maximum Standby Power at Rated RPM343KW/466HP
Compression Ratio14.0:1
Speed GovernorElectronic
Cooling SystemForced Water Cooling Cycle
Lub. oil capacity (L)36
Fuel Consumption, Stand-by (L/h)65
Starting MethodDC 24V Electrical starting
3. Specification of alternator
Alternator brandStamford
Alternator modelHCI444E
Number of Phase3
Connecting Type3 Phases and 4 Wires
Number of Bearing1
Protection GradeIP23
Altitude1000m
Exciter TypeBrushless ,Self-exciting, AVR automatic voltage regulating,100% Copper winding wire
Insulation ClassH
Telephone Influence Factor (TIF)50
THF2%
Voltage Regulation, Steady State±1%
Transient State Voltage-15%~+20%
4. Specification of control Panel(with Harsen controller)
The control panel is AMF control panel, with the display of voltage,current, frequency, water temperature, oil pressure. The genset with alarm of low oil pressure,high water temperature,over speed,over load protection function.

Prod Model: UPC350
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Cummins Engine: Nta855-G2a
Stamford Alternator: Hci444e
Delivery Time: 20days After 30% Deposit
Warranty Time: One Year or 1000hours
Payment Term: 30% Deposit by T/T, Balance Paid Before Shipping
Type: Self-Starting Diesel Generator
Installation Method: Fixed
Stroke: Four Stroke
Cooling Method: Water Cooling
Output Type: AC Three Phase
Speed: 1500rpm 50Hz
Excitation Mode: Self-Excited
Unite Power Industry Co.; Ltd is one professional manufacturer& exporter of diesel generator sets, gas genset, gasoline genset, genset, welding genset, etc. Power equipment, and power from 5kVA to 3000kVA, There are both domestic and abroad brand of engines we use like \Doosan Daewoo\Deutz, Shangchai\Yuchai\Jichai, Weichai, etc.

Unite Power, owns whole set of modern production equipments and is capable of testing 8 individual generators simultaneously and 2000KW gensets. Besides, its integrated production capacity also extends to production design, hardware stamping, R&D of mechanical and electrical equipments, etc. The annual output reaches 4, 000 sets.

Unite Power always insisted on scientific and technological innovation and dedicating itself to research and develop the technology of power products. We always work hard to attract a lot of scientific research, production and management talents, For long time, large amount of capital was invested in the update of technology, equipments and modern business management, which brings Unite Power not only strong research strengths but also integrated overall strength, and helps to win a high reputation in the market. Now, Unite Power becomes the well-known manufacturer &supplier in this field in the global market, and it is the main producing base for exporting.

Unite Power raises the quality into a vital important place, it formed a mature quality control system during the whole producing process, Customers are fully guaranteed by the caring detail pre-sales service, professional during-sales service and perfect after-sales service. Unite Power promises that the quality of every single diesel generator is committed to the customers' utmost satisfaction, meanwhile, also welcome kindly good partners from all over the world, on basis of win-win co-operations.

Management Concept:

"Sincerity, pragmatic, innovation" is our key values. The values lead us to succeed in our past. We believe it will guide us to win bigger success in the future. The credendum helps us to keep fast growth even in mature business environment. The good reputation is our most valuable resources. We always insist on handling over high-quality products and perfect service. We reach to exceed the customer's expectation all the time. Our Pragmatic team will throw ourselves to seek the best solution that we can offer whole heartedly.

Production capacity&Quality:

Unite Power generator set apply to outdoor, household, commercial mobile project, power ranging form 5kVA to 3000kVA. And the professional technicians devote to manufacturing good gensets with highest quality standard. Assembly line brings improvement on the productivity and efficiency as well as quality standard. At present, our monthly diesel generator productivity exceeds 1200 sets.

Before warehousing, the generators go through tests under various kind circumstances, including No-load, 50% load, 75% load, full load, and 110%load, in order to make sure every diesel generator has good performance at user's side. Every genset sold is with technical departments signed test reports. The first-class reliability and durability enable generator the ability to meet the harsh environments and high altitudes needs.
