A wind turbine, which is installed on top of a tall tower, collects kinetic energy from the wind and converts it to electricity that is compatible with a home's electrical system.
In a normal residential application, a home is served simultaneously by the wind turbine and a local utility. If the wind speeds are below cut-in speed (7-10 mph) there will be no output from the turbine and all of the needed power is purchased from the utility. As wind speeds increase, turbine output increases and the amount of power purchased from the utility is proportionately decreased. When the turbine produces more power than the house needs, the extra electricity is sold to the utility. All of this is done automatically. There are no batteries in a modern residential wind system.
Small wind systems for remote applications operate somewhat differently.
Rotor Diameter (m)
| 2 .8
|
Material and number of the blades
| FRB*3pcs
|
Rated power/maximum power
| 1000/1500w
|
Rated wind speed (m/s)
| 8
|
Startup wind speed (m/s)
| 2.5
|
Working wind speed (m/s)
| 3~25
|
Survived wind speed
| 50
|
Rated rotate speed(r/min)
| 450
|
Working voltage
| DC24V/48V
|
Generator style
| Three phase, permanent magnet
|
Charging method
| Constant voltage current saving
|
Speed regulation method
| Yaw+ Auto brake
|
Weight
| 70kg
|
Tower height (m)
| 9
|
Suggested battery capacity
| 12V/200HA Deep cycle battery 4pcs |
Life time
| 15years
|
EXMORK has for over 10 years been specializing in wind and water power products. We service everything we sell. We have seen scores of companies come and go, but we have consistently been here to take care of our customers. We supply good quality, low-priced renewable energy systems - proving that renewable power need not cost the earth. We've provided you very comprehensive alternative energy products, including complete systems, solar power panels, wind power generators, mini-hydro electric, inverters, and controllers. Our mission is to demonstrate that green energy is genuinely viable, whether you are living on or off grid - and that renewable energy can be a sound financial investment, as well as a sound investment in our future.
We believe that Alternative Energy products should not only be utilitarian, but also be aesthetically pleasing to look at. Our experience means that we will execute our services as efficiently as humanly possible. And lastly, we believe in innovation and creativity, finding new ways to serve our customers better.
Location:
Our company has manufacturing bases In Wenzhou.
Products:
At present, we specially manufacture and export small wind turbine, solar panel, micro hydro turbine, inverter and controller.
Overseas business partners:
We have established broad and friendly cooperation relations with more than 60 countries and regions. North and South America, The Middle East, Southeast Asia, Western Europe, Africa, Hongkong, Taiwan etc countries and regions.
Philosophy: What can we do for you?
Suitable product, suitable price, best service.
Creating value for Customers
The purpose is to continually create new value for customers.
In the process of creating value for customers, Exmork will naturally innovate and develop the products and services our customers want, moving us one step closer to our goal of providing the utmost value.
