| Price: | Negotiable/Piece |
|---|---|
| Trade Terms: | CIF |
| Min Order: | 1/Set |
| Pay Type: | L/C,T/T |
| On grid solar power supply system- SPB-500W | ||||
| System Basic Information | Solar panel rated output power: 500W Suitable for daily power consumption: < 2000WH Solar panel connect way: 4 pcs in parallel | |||
| Solar panel | type: mono solar panel()poly optional) Max power: 125w Vmp: 43.2V Imp 4.96A Size: 1218*812*35mm 25 years power output guarantee (CE TUV) | QTY 4pcs | ||
| Notes: 1. pictures show are for reference. 2. solar panel rack can be specially designed based on site condition Remark: 1)solar panel have 3 years warranty; 2)other parts have 2 years warranty; 3)ship the free parts for service(best service in china) 4)accept OEM | ||||
| On/off grid inverter | Power capacity: BF500W/24V MPPT range: Vpv( 21-36VDC) Perfect function: get the power to the grid, Also can take the load directly Protective Functions: Protection Against Over load, Short-Circuit, Over Heat, Anti-isolated Island Effiency, Polarity Joint-Reversed Allowed Voltage Range Of Grid: 90-130v or 220-240V AC | QTY 1pc | ||
| Solar panel rack | Flat – roof type mounting rack, No welding/ cutting at site, easy mounting. More options to select: Slope-roof mounting rack Array type rack; Standing – pole type rack | QTY 1set | ||
| Cables | 4m2cable, (one red and one black) International standard, with specification suitable for solar system, | 100m | ||
| Prod Model: | SP500w |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Product Name: | on and off Grid Solar Power System |
| 500W On Grid Power System: | 500W Solar Panel+500W on and off Grid Inverter |
| 1kw On Grid Power System: | 1kw Solar Panel+1kw on and off Grid Inverter |
| 2kw On Grid Power System: | 2kw Solar Panel +2kw on and off Grid Inverter |
| 3kw On Grid Power System: | 2.4kw Solar Panel+3kw on and off Grid Inverter |
| 5kw On Grid Power System: | 4kw Solar Panel+5kw on and off Grid Inverter |
| 10kw On Grid Power System: | 8kw Solar Panel+10kw Three Phase on Grid Inverter |
| 50kw On Grid Power System: | 38.4kw Solar Panel+50kw Three Phase on Grid Invert |
| OEM: | Accept |
| Warranty: | Solar Panel and Grid Inverter 5 Years Warranty |
| System: | Off-Grid system |
