500kw Coal Mine Gas Generator Set with Best Price

500kw Coal Mine Gas Generator Set with Best Price
Price: US $ 121000-123000/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 1/Piece
Pay Type: L/C,T/T,Western Union,Paypal
500kw Coal Mine Gas Generator Set with Best Price:
I.Products introduction:
Requirements of generator set to the coal bed gas:
Within 1m to the intake value of gas generator set
1,temperature≤40ºC
2,Pressure 3~20kpa,pressure changing rate≤1kpa/min
3,H2S≤200mg/Nm³;
4,If the CH4 covers less than 30%, the sum content of CH4 and O2 should not less than 28%,
the content of O2 should not less than 16%
5,Moisture content≤40mg/Nm³
6,Impurity Particle size≤5um,impurity content≤30mg/Nm³
If there are too much sulfur and ammonia in the gas, it will not only corrode the electrode of
sparking plug heavily but also increase the acid value of engine oil which will corrode the parts
inside of genset, easy to generate precipitate and increase the attrition corrosion to the engine.

II.Our products:
Applicable fuel for 190 Series Methane Biogas Power Generator has a wide
range of methane based gases (natural /PNG/LNG/CNG, oil field gas, biogas,
landfill gas, Methane Gss, marsh gas, coal mine methane gas and shale gas etc.).

III.Our advantages:
1.High quality
2.Stable stock
3.Competitive price
4.Technologist

Technical parameters of Coke oven gas /Coal gas /Semi-coke gas genset
Genset modeCW-300GFLCW-400GFLCW-500GFLCW-600GFL
Engine No.6190ZLDT-212V190DT-212V190ZLDT-212V190ZLT
Gas mix typeoutsideoutsideoutsideoutside
Rated power300kw400kw500kw600kw
Continuous power240KW320kw400kw500kw
Rated voltage400v/230v400v/230v400v/230v400v/230v
Phase3phase4wire3phase4wire3phase4wire3phase4wire
Rated frequency50Hz50Hz50Hz50Hz
Rated rotation1000r/min1000r/min1000r/min1000r/min
Rated power factor0.80.80.80.8
Rated current540A720A902A1020A
Frequency transient
regulating rate
≤0.5%≤0.5%≤0.5%≤0.5%
Voltage regulating range95-105%95-105%95-105%95-105%
Heat consumption≤11.5mj/kw.h≤11.5mj/kw.h≤11.5mj/kw.h≤11.5mj/kw.h
Lubricant oil consumption≤1.5g/kw.h≤1.5g/kw.h≤1.5g/kw.h≤1.5g/kw.h
Gas pressure80-200kpa80-200kpa80-200kpa80-200kpa
Cylinder number612-V12-V12-V
Cylinder diameter190mm190mm190mm190mm
Stroke210mm210mm210mm210mm
Compression ratio8:19:18:18:1
Starting mode24V electric motor24V electric motor24V electric motor24V electric motor
Overhaul time≥25000≥25000≥25000≥25000
Noise≤105≤105≤105≤105
Intake modeSupercharging ,
inter cooling
Natural intakeSupercharging,
inter cooling
Supercharging,
inter cooling
Ignition modePlug ignition Plug ignitionPlug ignitionPlug ignition
Pressure regulation modeautomaticautomaticautomaticautomatic
Speed regulation modeElectric speed
regulation
Electric speed
regulation
Electric speed
regulation
Electric speed
regulation
Lubrication modePressure and splashPressure and splashPressure and splashPressure and splash
Cooling modeClosed/open cooledClosed/open cooledClosed/open cooledClosed/open cooled
Exhaust temperature≤650ºC≤650ºC≤650ºC≤650ºC
Displacement35.7L71.45L71.45L71.45L
Genset size6000×1970×2235 6000×1970×2235 6000×1970×2735 6000×1970×2735

Contact Person:
Nancy Wu
Prod Model: CW-500GFJ
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Brand: Chargewe
Engine Brand: Jichai
Engine Model: 12V190zlt-2
Phase: 3p4w
Rated Frequency: 50Hz
Cylinder No.: 12
Cylinder Diameter: 190mm
Stroke: 210mm
Rated Speed: 1000r/Min
Rated Current: 902A
Gas Source: Gas
Shandong Chaiwei Power Equipment Co., Ltd is a comprehensive high-tech enterprises in China with more than 15 years experiences, focusing on new type of environmental protection generators' development production and sale. We have our own brand "CHARGEWE" generator set, including diesel generator set, biogas generator set, nature gas generator set, biomass generator set, coal gas generator set etc. From 20kw to 1000kw with CE & ISO9001: 2008 certificate, Besides we also offer the diesel engine and spare parts for gas/diesel generator set. Our products have been exported to Middle East, South America, Southeast Asia, Russia, Eastern Europe and have got a high reputation on the domestic and overseas market.

About the products, we have self-developed team to design and improve the generator sets to meet different customers` need. So the OEM and ODM are available. We have completed quality inspection system to make sure each product that customer get is perfect, and the professional after-sale team to guarantee your generator set be correctly installed and running normally. CHARGEWE will bring best products and service with most reasonable price for you. From the foundation of our company, we committed to leading as pioneer of the generator industry and contributing ourselves for China's electricity industry. We believe CHARGEWE will be your best partner in generator area.
