Home Generator Products 5000W Wind Generators for Remote Home

5000W Wind Generators for Remote Home

5000W Wind Generators for Remote Home
Price: US $ 5385/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 1/Piece
Pay Type: L/C,T/T
5000W wind generator for remote areas

1) Unique design:
The structure of 5000W wind generator is compact, it is made of refined materials, the generator is small in size, lighter in weight that can be placed inside the nose cone to reduce air resistance and increase output efficiency

2) High output efficiency
Due to the unique design, 5000W PMG can swiftly start up at 2.5m/s wind speed, the output efficiency of 5000W small wind turbine is more than 0.8, while the wind energy utilization ratio is as high as 0.4. The max output of it is 7500W

3) Stable operation of whole system
5000W small wind generators without tail wing and tail pole, but with a yaw shaft which is a major part of the control system, it does not only connects the generator and the tower, but also collects various working data of the system and environment like wind direction, wind speed, generator temperature etc. Also it will execute orders from the Siemens PLC controller to realize self protection, auto wind seeking etc.
Furthermore, inside the yaw shaft, there is a sealed gearbox, which can enhance the lifespan of the whole system.

Rated power (W)


5000


Maximum output power (W)


7500


Battery bank voltage (Vdc)


48V to 240


System output voltage (Vac)


110/220V single phase or 380V three phase


Start-up wind speed (m/s)


2.5


Rated wind speed (m/s)


10


Working wind speed (m/s)


3-25


Survival wind speed (m/s)


50



Generator type


Permanent Magnet Alternator


Generator weight (kg)


147


Blade material/quantity


GRP/3


Blade diameter (m)


6.4


Speed regulation method


Yawing+Electromagnetism braking

(Optional hydraulic braking)


Shutting down method


Manual+Automatic


Battery 12V150AH/200AH


20pcs


Warranty


2years


Certification


CE/UL/ISO/BV


Prod Model: H6.4-5000
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Rated Output Power: 5000W
Max Output Power: 7500W
Blade Diameter: 6.4m
Cut In Wind Speed: 2.5m/S
Rated Wind Speed: 10m/S
Working Wind Speed: 3m/S to 25m/S
Survival Wind Speed: 50m/S
Over Wind Speed: Electromagnetism Brake, Yawing
Battery: Gel Storage Battery Bank
Tower: 12m Guyed Tower
Number Of Blade: Three Blade
Rotating Shaft: Horizontal
Stress Way Of Blade: Resistance
Phase: Three Phase
Anhui Hummer Dynamo Co., Ltd. is a professional wind generators manufacturer with high-tech in the field of wind energy.

We specialize in researching, developing, producing and promoting of small-sized wind generator system, and also provide solutions for setting up small-scaled wind farm. After nearly 30 years efforts, our company has developed independent intellectual property rights of "Hummer" wind generator and control system.

There are more than 200 employees in the company including 40 R&D staff. And the factory covers over 30, 000 square meters with the workshop more than 7.5 Acres. There are more than 100 sets of large machines for processing, cutting and spray-painting equipments, and also many testing and examining systems. The monthly output is 3, 000 sets.

All Hummer small-sized wind generators including wind generator from 400W to 200KW, which have acquired CE certificate. Meanwhile, Hummer' S wind generator with good reputation can be found in more than 91 countries and regions, such as EU, North America, Oceania, Africa and Asia.

Hummer' S wind generators have the features of "Super Light, Small, Swift and High efficiency" when comparing with traditional' S. We have a powerful R&D team (consisting of experts enjoying government allowance), providing a reliable strength for product upgrade& technical support. The management team has abundant experiences in production, marketing, service and consultation. Until now our company has formed a comprehensive management system of research, study, development and service.

Hummer aims to be a worldwide influential enterprise as well as the best domestic manufacturer and service provider.
