Product Description
5kW silent liquefied petroleum gas generator, which uses special technology. It has advantage of safety, enviromental.
The generator is assitant for home, outdoor and emergency power.
LPG Generator VS Gasoline Generator:
Simple & easy to operate & use
Simple & easy to maintain & repair, less trouble
Cost saving, about 30% to 70% running cost lower than gasoline generator sets
More durable & more reliable, longer life than gasoline generator sets.
Cleaner emission, no smoke, no smell, healthier for people and the environment
How to produce?
1. ERP system and 5S management support the whole producing.
2. Choose spare parts from Honda, B&S supplier.
3. Check the spare parts according to TS 16949.
4. Clean the spare parts before assembling.
5. Advanced assembly line includes robot, SPC and etc.
6. 100% testing.
7. Packing.
Why us?
1. Visible quality and quality control.
2. Warrenty: 1 year.
3. R&D according to demand.
Packaging & Shipping
Packaging: carton box or according to demand for gasoline generator.
Shipping: 15 to 30 days for gasoline generator.
Model | TG5000-LPG |
Rated Frequency(Hz) | 50 | 60 |
Rated Power(kW) | 4.6 | 4.7 |
Maximum Power(kW) | 5.0 | 5.2 |
Rated Voltage(V) | 220/380 | 240/120 |
Rated Current(A) | 20.9/12.1 | 19.6/19.6 |
Speed(RPM) | 3000 | 3600 |
Power Factor (cosφ) | 1.0 |
Excitation | Self-excitation |
DC Output | 12V/8.3A |
Voltage Adjustment System | Automatic Voltage Regulator(AVR) |
Adjustment Rate of Steady Voltage | ≤±5% |
Adjustment Rate of Steady Frequency | ≤±5% |
Insulation Resistance (Cold State) | ≥200MΩ |
Engine Model | T188F-LPG |
Engine Type | Single Cylinder, 4-stroke, OHV, Forced Air-cooled |
Bore×Stroke (mm) | 88×64 |
Displacement (CC) | 389 |
Ignition System | T.C.I. |
Starting Mode | Recoil/Electric Starter (standard) |
Sound level @ 7 meter Full Load (dB) | 77 |
Lube Oil Capacity (L) | 0.9 |
Lube Oil Type | SAE10W-30, <4°C , SAE10W-40, >4°C |
Fuel Consumption (Rated Power) | LPG: 0.33kg/kW · hr |
Rated Engine Power (kW) | LPG: 7.6/3600 |
Yancheng Talos Engine Equipment Co., Ltd., which does business of engine equipment. The products including products related to engine, such as generator, water pump, lawn mower, chain saw, snow blower, construction equipment, spare parts and etc.
From year of 2008 to 2015, our products have been servered millions of people European, Northern America, South America. Our team have many years' working experience in factory, thus we are professional of products.
The feature of our products: Durable, good quality, reasonable price.
Our products make you work easy!
Our products make you low cost of maintance!
