Prepackaged unit with prewired manual transfer switch with 16 circuits and enough power to start a 5-ton A/C unit or two 4-ton units!
OHV engine's automotive-type full pressure lubrication system eliminates wear during start up and provides max.
Lubrication and cooling during the most demanding conditions. Includes maintenance-free battery and pneumatic wheel kit.
EPA and CARB certified.
| Generator | Rated frequency (Hz): | 50 | 60 |
| Rated voltage (V): | 230 | 120 |
| Rated output power (kW): | 5 | 5.5 |
| Max output power (kW): | 5.5 | 6 |
| Rated rotation speed (rpm): | 3000 | 3600 |
| DC output: | 12V 8A |
| Power factor cos: | 1 |
| Phase number : | Single phase |
| Noise level dB (A)/7m (zero load-full load): | 70-74 |
| Fule tank[L]: | 25 |
| Set | Overall dimensions [mm] ( L x W x H ): | 630x535x635 |
| N.W/G.W[Kg]: | 78.5/80.5 |
| Engine | Engine model: | ZH390 |
| Engine type: | single cylinder, 4-stroke, air-cooled, OHV, gasoline engine |
| Displacement [cc]: | 389 |
| Compression ratio: | 8.5:1 |
| Rated power [(HP/rpm]: | 13.0/3600 |
| Rated rotation speed (rpm): | 3600 |
| T.C.I: | with |
| Spark plug: | F6RTC |
| Starting system: | recoil starter or electric starter |
| Rotation direction (view from flywheel): | clockwise |
| Fuel type: | automotive unleaded gasoline |
| Lube oil brand: | SAE10W30 (above CC grade) |
| Low oil alarm system : | With |
Taizhou Genour Power Machinery Co., Ltd was established in 2003, is the leading manufacturer, exporter of quality products in the engine, generator and water pump business. Employing over 300 staff, and high intermediate technical personnel accounts for above 20%. Taizhou Genour has its Head Office in Fenxi Industrial area, Duqiao Town, Taizhou city, Zhejiang. Factory building area covers about 20, 000 square meters. It is capable to produce 200, 000 sets a year.
Manufacturing includes, gasoline engine, gasoline generator, gasoline water pumps, gasoline concrete vibrator, gasoline generator with welding, diesel engine, diesel generator, diesel water pump, pressure washer and so on. Our sales network covers Europe, East Europe, South America, Southeast Asia, Africa and Middle East area etc., our products are exported to more than 65 countries.
We pay much more attention to the quality of products, and has been certified by ISO9000 and ISO 14000. Each step of manufacture is carried out with strict adherence to the standards of these certifications. While many products have gotten CE, EMC, NOISE, GS, SONCAP and EPA certifications to constantly bring our customers reliable and high-quality products. You can count on us for quick and economical after-sale service solutions due to our well-trained worldwide dealer network. It is always our goal to develop our brand recognition based on exceptional customer service, and to be a contributing member to our employees and the communities in which we do business, both economically and socially!
We are looking forward to going hand in hand with you and co-create resplendence.
