Alternator parts for gasoline generator (1kw-7kw)
1. Stator & Rotor can be designed by our customers
2. CCC, CE, RoHS, UL approvel
3. Good quality
Products Features
1, Portable emergency power supply when working with gasoline generator;
2, Monophase(TFD) or three phase(TFS) AC power output;
3, Brush excitation and brushless excitation model available;
4, AVR (automatic voltage regulator) makes the stable voltage output (TFD brush excitation);
5, The capacitance compensation makes easy maintenance and reliable operation (TFDWBrushless excitation).
6, CE/TUV certificate approved;
7, Rotor&stator can be develop according to client's request;
8, Parts list: Stator +Rotor(Include Ball Bearing & Radiator Fan) + Protect Plate + Electric Brush;
Packaging & Delivery
Packaging Detail: Foam material+carton+container
Delivery Detail 30 days after receipt of the deposit
|
Type |
Rated Frequency
(HZ) |
Rated Power
(KW) |
Max. Output Power
(KW) |
Operation Method |
THDu% |
Phase |
External Dimension |
|
Diameter D (mm) |
Length
L (mm) |
Matching
Taper |
|
TFD190-4.0 |
50/60 |
4.0 |
4.5 |
S1 |
≤15% |
1 |
190 |
125 |
1:5 |
|
Insulation Class |
B (T≤85K) & F (T≤105K) |
|
Power Factor (cosφ) |
cosφ=1 |
|
Rated Voltage (V) |
110,115,120,220,230,240,110/220,120/240,230/400 |
|
DC Output |
No-DC Output |
DC Output 12V / 8.3A |
|
Excitation |
Brush-excitation |
|
Taper ratio |
Honda engine matching taper is 1:5.333 (3:16) |
Shaoxing Xiduo Electric Machine Co., Ltd is a high-tech enterprise integrating production with marketing.It is situated in Shanggao Industrial Park, Shengzhou, Zhejiang province.Our company supplys different kinds of products.High quality and favaroble price.We're pleased to get your Inquiry and we will come back to as soon as possible.
