Shanghai STONE DIESEL ENGINE Co., Ltd CAN SUPPLY THE ISUZU DIESEL ENGINE 4JA1 4JB1 4JB1T DIESEL ENGINE.
Type Model Cyl Bore/Stroke Capacity Power KW/RPM Torque /RPM Dimension Weight
CUMMINS 4BT 4 102/120 * 3.92 * 77/2800 * 334/1600 *778x634x912 *355
CUMMINS 4BTA 4 102/120 3.92 88/2800 380/1600 778x634x912 355
CUMMINS 6BT 6 102/120 5.88 118/2600 558.6/1500 1026x699x912 443
CUMMINS 6BTA 6 102/120 5.88 132/2500 617/1500 1026x699x912 443
CUMMINS 6BTAA 6 102/120 5.88 155/2500 617/1500 1026x699x912 443
CUMMINS 6CT 6 114/135 8.3 180/2200 796/1500 1115x716x751 617
CUMMINS 6CTA 6 114/135 8.3 191/2200 796/1500 1115x716x751 617
CUMMINS 4BTA3.9-G 4 102/120 3.9 50/1500 778x634x912 370
CUMMINS 6BT5.9-G 6 102/120 5.9 97/1500 1026x699x912 450
CUMMINS 6BTAA5.9-G 6 102/120 5.9 120/1500 1026x699x912 450
CUMMINS 6CT8.3-G 6 114/135 8.3 122/1500 1115x716x751 620
CUMMINS 6CTA8.3-G 6 114/135 8.3 159/1500 1115x716x751 620
ISUZU 4JB1 4 93/102 2.77 57/3600 172/2200 833x580x700 124
ISUZU 4JB1T 4 93/102 2.77 68/3600 202/2200 833x580x700 130
ISUZU 4BD1 4 102/118 3.85 70.6/3200 245/2200 921x651x751 330
ISUZU 4BD1T 4 102/118 3.86 83/2800 324/1800 790x660x820 340
ISUZU 6BD1 6 102/118 5.78 103/3000 372/2000 1286x660x870 480
ISUZU 6BD1T 6 102/118 5.78 120/2800 460/1800 1286x700x970 555
ISUZU 4HF1 4 112/110 4.334 110/2600 460/1500 1121.5*615.5*743.5 350
ISUZU 4HE1T 4 110/125 4.751 125/2300 580/1500 1181*699.8*833.3 365
DEUTZ F6L413F 6 125/130 77-141/1500 613 1047*1038*860
DEUTZ F8L413F 8 125/130 103-180/1500-2650 817 1211*1038*860
DEUTZ BF8L413F 8 125/130 12.76 235/2500 1080/1650 1452*1138*1042 920
DEUTZ F12L413F 12 125/130 282/1500 1226 1575*1038*956
DEUTZ F12L413FC 12 125/130 282/1500 1226 1575*1038*956
DEUTZ BF6L513 6 125/130 10.68 177/2300 905/1500 1506*790*1018 865
DEUTZ BF8L513 8 125/130 12.76 243/2300 1170/1500 1452*1138*1042 920
DEUTZ BF8L513FL 8 125/130 235/2300 1170 1575*1038*956
DEUTZ BF12L513FLC 12 125/130 19.144 386/2300 1900 1580*1192*1099
DEUTZ BF6L513FLRC 6 125/130 10.676 177/2100 941 1506*790*1036 865
DEUTZ F3L912 3 100/120 2.82 44/2500 170/1600 1200x880x1150 270
DEUTZ F4L912 4 100/120 3.77 51/2500 230/1600 1200x880x1150 300
DEUTZ F6L912 6 100/120 5.65 78/2500 345/1600 1450x980x1200 410
DEUTZ F4L913 4 102/125 4.09 56/2500 255/1600 1200x880x1150 322
DEUTZ F6L913 6 102/125 6.13 85/2500 384/1600 1450x980x1200 454
DEUTZ BF4L913 6 102/125 4.09 78/2500 342/1650 1200x880x1150 350
DEUTZ BF6L913 6 102/125 6.13 118/2500 490/1700 1550x1050x1200 515
DEUTZ F3L912 3 100/120 2.82 26.5/1500 1200x880x1150 270
DEUTZ F4L912 4 100/120 3.77 35/1500 1200x880x1150 300
DEUTZ F6L912 6 100/120 5.65 53/1500 1450x980x1200 410
DEUTZ BF4M1013 4 108/130 4.764 117-140/2300
DEUTZ BF6M1013 6 108/130 7.146 177-220/2300
DEUTZ BF4M2012 4 108/126 4.04 90-118/2500
DEUTZ BF6M2012 6 108/126 6.06 118-170/2500
DEUTZ BF6M1015 6 132/145 11.906 195-352/1500-1800
DEUTZ BF8M1015 8 132/145 15.874 333-469/1500-1800
DEUTZ TCD2015V6 6 132/145 11.906
DEUTZ TCD2015V8 6 132/145 11.906
DEUTZ TD226B-3 3 105/120 3.12 45/1500 800x600x950 280
DEUTZ TD226B-4 4 105/120 4.16 55/1500 1000x600x950 320
DEUTZ TD226B-6 6 105/120 6.23 88/1500 1400x600x1000 430
PERKINS 1004-4 4 100/127 3.99 58/2200 280/1800 711x610x767 273
PERKINS 1004-4T 4 100/127 3.99 83/2400 354/1800 711x614x767 279
PERKINS 1006-6 6 100/127 5.99 96.5/2200 427/1800 945x610x780 410
PERKINS 1006-6T 6 100/127 5.99 119/2400 529/1800 945x677x780 419
PERKINS PHASER 135Ti 4 100/127 3.99 101/2500 445/1600 711x702x782 292
PERKINS PHASER 160Ti 6 100/127 3.99 118/2500 555/1600 745x755x854 419
PERKINS PHASER 180Ti
PERKINS PHASER 210Ti
PERKINS 1004G 4
PERKINS 1004TG 4
PERKINS 1006TG1A 6
PERKINS 1006TG2A 6
PERKINS 1006TAG 6
Iveco 8140.27S 4
Iveco 8140.47 4
Iveco 8140.23 4
Iveco 8140.43 4
Iveco 8140.43C 4
Iveco 8140.43Z 4
Iveco 8140.43S 4
Iveco 8140.43N 4
Shanghai STONE DIESEL ENGINE Co., Ltd
As a leading manufacturer and supplier in China, Shanghai Stone Diesel Engine Co., Ltd is specialized in complete engine DEUTZ/KHD, CUMMINS, ISUZU and CATERPILLAR. We are also the supplier spare parts. Such as crankshaft, camshaft, con rod, cylinder head, cylinder block, cylinder liner, piston, piston ring, engine valve, engine bearing, oil nozzle, oil seal, oil pump, fuel pump, water pump, turbocharger, and so on.
Our products have exported many countrys.
Shanghai Stone Diesel Engine Co., Ltd supply the China products which are made by joint venture with international engine and engine parts, for example MAHLE IZUMI, Mahle, Elring, Bosch, Payen, Federal-mogul, TP, Holset, S. Valeo, Garrett, Borg-Warner, KKK, ZF, Eaton, Fuller, GKN, Thomson products which made in China under strict quality control and international quality standards.
We aim to be a top class supplier for worldwide OEM and aftermarket!
Hope build good business relationship with all company which is do business in this field.
