48V 2000W Low Speed Vertical Axis Wind Turbine (YC-NEW2000)
Price: |
Negotiable/Piece |
Trade Terms: |
FOB,CFR,CIF |
Min Order: |
1/Piece |
Pay Type: |
T/T,Western Union |
Application:Suitable for any Application; Urban to Rural, Residential to Commercial, Industrial to InstitutionalAdvantages of VAWT:Nearly Quiet
More Safety
Captures Wind From Any Direction
Birds Friendly
Longer Working Life
Less Maintenance
Less Requirements on Foundation
Lower Supporting TowerFeatures from Other VAWT:Pitch Control to Govern Speed
Automatic Mechanical BrakePower Range: 200W-50KW
Vortex-type vertical axis wind turbine:
Eddy vertical axis windmill is a windmill from a fixed stator and a rotor rotating component, can be placed in the city to use. It provides energy in the production of new urban centers may be, and very beautiful. Technically structural framework, it is suitable for strong turbulence characteristics of regions and cities of modern buildings the wind.
Aerodynamic characteristics:
Windmill axisymmetric features allow it to fully accept any direction of the wind. In fact, the stationary stator and rotor blades of the rotor blades in a symmetrical manner around the vertical axis wind turbine distribution, while taking advantage of the wind in any direction to run. Thus leading to an optimal operating condition, regardless of which direction the wind, are very useful to take measures to make this structure often changes the direction of the turbulent flow through the windmill to make a better run
Stator principle(1):
Using the stator of the three major advantages:
1. First, in order to generate maximum power, the stator can be the best way to lower surface of the rotor blades on the air flow leads to a direction.
Stator principle(2):
2. The stator windmill provides a rigid tubular structure to include the possibility of fans, it can anti-wind the stator windmill (fresh gale), and also to make up for a variety of aerodynamic vibration and stress (compatible with the blade cyclone, torque for the spindle cycle...).
Stator principle(3):
3. More than the rated wind speed, when the rotor blades on the surface facing the wind, when the normal rotation produces a torque in the opposite direction. This is why the stator wind deflector design point is the key reason. In this region is called the turbulence generated within the "brake", and turbulence "brake" to prevent the penetration of wind turbine rotor, and thus make it slow. Turbulent region is generated by the stator, in order to prevent penetration into the fan in the wind
2KW Wind Turbine |
Total Power | 2KW |
Blade Diameter | 3.2m |
Blade Height | 2.6m |
Blades Number | 6 |
Blade Material | Aluminum Alloy |
Rated Rotated Speed | 75r/min |
Start Up Wind Speed | 2m/s |
Rated Power | 2KW |
Max Power | 2.2KW |
Rated Voltage | DC 48V |
Rated Speed | 12m/s |
Security Wind Speed | 35m/s |
Top Quality Except Tower | 600kg |
2KW Wind Charge Controller |
Rated Battery Voltage | DC 48V |
Rated Power | 2KW |
Wind Turbine Brake Current | 42A |
Floating Charge Voltage | 58V |
Dump Load Control Mode | PWM |
Display Mode | LCD |
Quiescent Current | ≤20 mA |
Ambient Temperature & Humidity Range | -20~+55ºC/35~85%RH(Without Condensation) |
Dimension | 445×425×170mm |
Net weight | 12kg |
Prod Model: |
YC-NEW2000 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Rated Power: |
2000W |
Maxed Power: |
2200W |
Start Wind Speed: |
2m/S |
Rated Rotated Speed: |
12m/S |
Survival Wind Speed: |
35m/S |
Rated Voltage: |
DC 48V |
Rotating Shaft: |
Vertical |
Stress Way Of Blade: |
Resistance |
Number Of Blade: |
9pieces |
Power: |
2000W |
Phase: |
Three-Phase |
