Wind turbine generator: Vertical axis wind turbine. Hybrid model has small size, and simple design. It fully uses lift and drag force, easily products rated power at low wind speed. 3 Phase Permanent Magnet AC Generator, direct driven, no gearbox, and not need windward.
Power: 50W 100W 200W 300W 500W 1000W 2000W 3KW 5KW
VAWT(USD/SET): 470 500 540 600 770 1100 2100 4250 6100
CONTROLLER(USD/SET): 80 90 95 100 130 160 200 330 390
INVERTOR(USD/SET): 170 370 485 760 1050 1750
RATED SPEED(m/s): 8 8 8 8 8 8 10 10 10
OUT DC (v): 12 12 12 24 24 48 48 48 220
SETUP SPEED(m/s): 2 2 2 2 2 2 2 3 3
WORKING SPEED(m/s): 3-20 3-20 3-20 3-20 3-20 3-20 3-20 3-20 3-20
SAFE SPEED(m/s): 40 40 40 40 40 40 40 40 40
HEIGHT OF TOWER(m): 6 6 6 6 6 6 6 8 9
Type OF TOWER(mm): 60× 3 60× 3 60× 3 60× 3 75× 4 75× 4 89× 4 133× 5 159× 5
PRICE TERM: FOB QINGDAO
It has perfect performance. With low rpm of generator; Controller can be PWM, on grid; Invertor can be pure sine wave with automatic on-grid interface or directlt on grid invertor.
Main advantages of this product
1. Small size.
2. Silent as vertical wind turbine.
3. Simple installation, only need to connect generator with flange.
4. The invertor is power efficiency, and sine wave. It has good performance when facing instantaneous high voltage when we start pump, fridge, etc.
5. We have PWM controller, which can make output voltage steady.
Qingdao CTturbine New Energy Co., Ltd is specializing in developing, producing and exporting new type of vertical axis wind turbine and relevant products with brand "CTTURBINE". We already held several patents and have a professional team of designer, engineers with 10 years experience in this field. We have the strict production management and ISO quality control system, also have got the CE certification. And our wind turbine are well sold in the worldwide.
Vertical axis wind turbine is a model among energy-savings, and will play a more important role in various fields than HAWT. We are willing to expand market with anybody who is interested in new energy together, and welcome more people come to know more about our loved VAWT all over the world.
