Important Characteristics of Configured Complete Vehicles
1. The power supply complement of complete vehicle is convenient and the battery power can be complemented in time, which solve the problems such as insufficient endurance of pure electric power and long-term frequent under voltage operation of battery, and provide a good protection for the battery.
2. The program is meticulous and simple, and the performance is stable, the reliability is strong and the price advantage is obvious.
3. The wiring is easily understood; For the wiring of complete machine, the alternator 3-phase wires need to be connected into the rectifier bridge of which positive and negative poles are connected at two ends of the battery.
4. The operation is simple; After the battery has run down, it is needed only to set the kill switch to ON position, and then provide the power for complete vehicle through recoil start/ electric start for ignition.
5. The generator is permanent magnet DC brushless type so that the volume of range extender can be smaller than excitation generator, with reliable performance, low power loss and longer life.
6. Series oil-electric hybrid mode is used, and the complete machine is composed of the generator and rectifier bridge with compact conformation which is suitable with numerous models.
7. Recoil/electric start modes can be selected by user for start and ignition; It has a speed control actuator, with such advantages as constant power speed, stable generation voltage and convenient operation and maintenance.
8. The generator supplies the power for driving of complete vehicle, and the residual energy is stored in the battery. Ease vehicle mileage range.
9. In case the battery has run down, it will supply the power for complete vehicle to increase endurance mileage.
|
Item Model |
TSZ3000B |
|
Engine |
Engine Type |
Single cylinder\4-stroke\forced air-cooled\OHV |
|
Bore×Stroke(mm×mm) |
70×54 |
|
Displacement (ml) |
208 |
|
Compression ratio |
8.5:1 |
|
Rated power(kw/rpm) |
4.0/3600 |
|
Ignition system |
Transistorized magneto ignition |
|
Start mode |
Recoil / Electric start |
|
Oil grade |
10W30 SAE |
|
Oil capacity (L) |
0.6 |
|
Fuel type |
≥#90 gasoline |
|
Alternator |
Rated voltage(VDC) |
48/60/72 |
|
Rated power(W) |
≥2500 |
|
Rated speed(r/min) |
3300 |
|
Range Extender |
Fuel tank capacity(L) |
3.6 |
100KM
Fuel consumption 100km |
<3.5L |
|
Noise (dBA) |
≤60dB/5 meter(can be adjusted subject to silencer) |
|
Dimensions(L×W×H)(mm) |
360×286×267(excluding fuel tank) |
|
Net weight(Kg) |
≤14 ( excluding fuel tank and silencer ) |
|
|
|
