1. CE approved, powered by POK advanced air-cooled diesel engine.
2. Noise-reducing enclosure, made of high-efficient noise-proof material.
3. Ideal for home emergency use or as standby power supply.
4. Large fuel tank, ensuring hours of continuous output.
5. Advanced direct fuel injection system.
6. Large silent muffler & air-cleaner, reducing exhaust and intake noise.
7. A variety of specially-designed control panels available for different markets.
|
Model |
POK3500X/XE |
|
Rated frequency (Hz) |
50 |
60 |
|
Rated voltage (V) |
220, 230, 240, 110/220, 115/230, 120/240 |
|
Rated output power (KVA) |
2.6 |
3 |
|
Max output power (KVA) |
3 |
3.3 |
|
Rated rotation speed (rpm) |
3000 |
3600 |
|
Power factor cosφ |
1 |
|
Phase number |
Single |
|
Pole number |
2 |
|
Excitation transistorized |
Self-excitation, brushless |
|
ATS type |
Without ATS, optional |
|
Structure type |
Open-frame |
|
Fuel consumption (g/KW. h) |
370 |
|
Fuel tank capacity (L) |
12.5 |
|
Continuous running time (hr)(at rated power) |
14 |
|
Noise level (dBA@7m) (zero load ~ full load) |
72-77 |
|
Net weight (kg) |
X: 65 |
XE: 70 |
|
Overall dimension (mm)(L× W× H) |
705× 460× 535 |
|
Starting system |
X: recoil starter; XE: electric starter |
|
Fuel type |
0 (summer), -10 (winter), -35 (chill cold) diesel oil |
|
Lube |
SAE10W30 (above CC grade)) |
|
Engine model |
X: POK178F |
|
XE: POK178FE |
|
Engine type |
1-cylinder, 4-stroke, air-cooled, verical, diesel engine |
|
Bore× stroke (mm) |
78× 62 |
|
Displacement (cm³ ) |
0.296 |
|
Compression ratio |
20: 1 |
|
Rated power (KW/rpm) |
3.7/3000 |
4.0/3600 |
|
Rotation direction (view from the flywheel) |
Clockwise |
