The HFD01-300WC vertical axis permanent magnet wind generator is an advanced and unique product. it could help you solve problems of energy shortage and rise your life quality.
|
Blade number |
3 |
|
Blade Material |
Glass fiber |
|
Generator type |
Permanent Magnet Generator |
|
Wind round of direct |
1.3m |
|
Wind coefficient(CP) |
0.43 |
|
Rated voltage |
28DC |
|
Rated power |
300W |
|
Maximum power |
450W |
|
Start up wind speed |
2.5 m/s |
|
Cut in wind speed |
3-3.5m/s |
|
Rated wind speed |
8m/s |
|
Wind speed automatic brake |
m/s,Average wind speed 30.6 |
|
Rated speed |
300rpm |
|
Speed ratio |
0.39 |
|
Brake Protection System |
Mechanical Automatic constant speed device / Manual |
|
Product life |
15 years |
|
Warranty period |
2 years |
|
Net weight |
11kg/33kg |
|
Packing |
Carton and foam. |
|
Package Size |
Blade:1400mm*350*mm*350mm,Generator:300mm*300mm*280mm |
|
Ambient air temperature |
-30~+50C |
|
Country of Origin |
China |
|
Annex |
Wind light controller |
|
Usage |
Configured to use Wind light complementary inverter
Output Voltage 110/120/220/230/240VAC |
