1. permanent magnet
2. sine wave
3. high sensitive&low noise
4. lagre power, widly usage
5. ce&rohs
detailed description
adopt high-quality and high-strength permanent materials to ensure high energy conversion efficiency.
adopt high-quality and high-strength aluminum alloy to make the unit light weight and easy installation.
the fiber-glass blades have the advantages of great intensity and excellent fatigue resistance.
stainless steel shaft and screws to avoid rust and corrosion.
and the surface is coated with pollution-free material. working environmental temperature from -20c-50c.
electromagnetic brake is with the function of over-speed and over-current protection.
about windturbine&windmill
a wind turbine is a device that converts kinetic energy from the wind, also called wind energy, into mechanical energy; a process known as wind power. if the mechanical energy is used to produce electricity, the device may be called wind turbine or wind power plant. if the mechanical energy is used to drive machinery, such as for grinding grain or pumping water, the device is called a windmill or wind pump. similarly, it may be called wind charger when it is used to charge batteries.
today's wind turbines are manufactured in a wide range of vertical and horizontal axis types. the smallest turbines are used for applications such as battery charging or auxiliary power on boats; while large grid-connected arrays of turbines are becoming an increasingly important source of wind power-produced commercial electricity.
power |
3KW |
5KW |
the diameter of wind wheel |
3m |
4m |
blades number |
3 |
5 |
blades length |
3.6m |
3.7m |
rated rotate speed |
150(r/min) |
100(r/min) |
rated wind speed |
9-11m/s |
7-8 m/s |
start up wind speed |
3m/s |
3.2m/s |
working wind speed |
3-25m/s |
3.2-25m/s |
security wind speed |
50m/s |
50m/s |
rated power |
3KW |
5KW |
the max power |
4.5KW |
6.5KW |
output voltage(DC) |
AC220V/380V |
AC220V/380V |
the height of free stand tower |
8m |
8 m |
output control system |
charger control, inverter |
charger control, inverter |
battery reference |
12v100ah 18pcs |
12V120ah, 18 pcs |
