Performance characteristic:
*Mon/polycrystalline soalr panel constitute the soalr square array in series or parallel.
*Highly-efficient intelligent automatically solar charge or discharge controller, Multistage PWM charging mode and MPPT tracking technology, take advantage of the solar source array efficiency completely, all-directional protect the battery and prolong life.
*Deep circulating battery system, get more power effectively
*Sine wave inverter, make the solar power system connect with public, complement each other
*Simple, quakeproof, anticorrosion bracket, Install conveniently.
Warranty:
*2years maintenance-free for the whole set.
Application:
*For using widely communication equipment, rural electrification, movable eisure house car, school, hospital, etc
|
|
SW-SPS3.0KW |
SW-SPS4.0W |
SW-SPS5.0W |
|
|
|
|
Power of solar panel |
3000W |
4000W |
5000W |
|
|
|
|
Capacity of battery |
48V/450AH |
48V/800AH |
48V/1000AH |
|
|
|
|
Controller |
48V/ 80A |
48V/ 80A |
48V/ 80A |
|
|
|
|
Inverter |
3KVA |
5KVA |
5KVA |
|
|
|
|
Output voltage |
DC 48V/AC 220V(110V) |
DC 48V/ AC 220V(110V) |
DC110V/AC 220V(110V) |
|
|
|
|
Working duration |
Daily electricity consumption can be 10KWh~16.0KWh, working duration will be different for varied loads. |
|
|
|
|
Operating temperature |
-20 º C ~+65 º C |
|
|
|
|
Battery breaker rating |
80A |
125A |
125A |
|
|
|
|
PV cables |
1*4mm 2, length 70 meters |
1*4mm 2, length 100 meters |
1*4mm 2, length 120 meters |
|
|
Battery charge cables |
1*16mm 2, Length 20 meters |
|
|
Inverter input cables |
1*25mm 2, Length 14 meters |
1*35mm 2, Length 18 meters |
|
