FEATURES:
High-power IGBT intelligent power module to guarantee high reliability
4-quadrant operation and variable speed constant frequency control of doubly-fed wind turbine available, grid-connected PF adjustable
A new high-speed floating-point DSP processors to achieve stronger operation ability and more optimal control
Optical fiber transmission to prevent electromagnetic interference
Perfect protection and display
Modular design, easy to install and maintain
High reliability design suitable for severe operation and transport condition in the wind farm
Rated Power
2000kW
Grid-side Voltage Range
690VAC (three-phase)+10%/-20%
Grid-side Frequency Range
50/60 Hz
Rated Current
1700A
Efficiency
0.97(at rated power)
Operation Ambient Temp.
-25~+45
Storage Ambient Temp.
-40~+65
Altitude
0~2000m(above 1000m, the current is derated)
Environmental Humidity
< 90%
Cooling
Water cooling
Protection Level
IP23
Protection
Grid abnormal, short circuit, overload, over-temperature, over-voltage, earth fault, communications failure etc.
Dimensions(W × H× D)
2*(2300*2100*700)(mm)(2 cabinets
