Engine Model: XD3500
Model: 178F
Type: Forced air-cooled 4-stroke OHV single cylinder, diesel engine
Displacement(ml): 296
Max output(hp): 7
Starting System: Recoil and hand-operated, Electric-operated
Deameter*Stroke(mm)DxS: 78x62
Rated rotation speed(r/min): 3000 3600
Rated power(kw/ps): 3.68/5 4/5.5
Fuel consumption(g/kw/h): ≤ 4.08
Crank cumgyrate direction deasil: Viewed from flywheel
Lubricate mode: Pressure splash
Fuel Tank Capacity(l): 12.5
Continuous Operating Hours(h): 9.5h(50Hz)//7.5h(60Hz)
Engine Oil Capacity: 1.1
Operating Noise at 7m(db): 83(50Hz)//86(60Hz)
Generator
Phase Number: Single phase Three phase
Rated Frequency(hz): 50/60 50/60
Rated Voltage(v): 220/110 380/220
Power Factor: 1
Rated output(kw): 3
Max AC Output(kw): 3.5
DC Output in Low Voltage: 12V, 8.3A
Dimension LxWxH(mm): 660x490x550
Packing: Brown carton
N. W. /G. W. (kg): 77/80
20GP/40GP: 148/320
Taizhou Xinggang Mechanical and Electrical Co., Ltd. is an enterprise specializes in power machinery, established in 2001. Nowadays, the main products are gasoline generator, diesel generators, chainsaw and Brush cutter, our products are well accepted by the global market with its favorable prices and High quality.
Our company is consisted of "Press Casting Factory", "Metal Cutting Factory" and " Generator Factory". There are more than 150 employees, including about 20 various engineers and technicians. We could produce and assemble all kinds of gasoline or diesel generator 100, 000sets per year. Our company owns import & export right, 80% of the products are exported, and we have passed the 3C National Compellent Product Certificate, the ISO9001/2000 Quality Management Certificate and CE certificate.
Our company believes that "preciseness, sincerity, Development and Service" is the foundation of us, and we insists the "Quality first, aiming precision, constant improving and customer's satisfaction" as our quality principle. Meanwhile, we take "innovation" as the soul of the company. We would like to cooperate with friends from worldwide to develop our splendid future. Your OEM business is also welcome!
