China made Hummer 2kw small domestic wind turbine
Hummer H3.8-2000 is a typical HUMMER small wind turbine below 3KW. It gives you a clear look how small hummer generator is, which is able to be placed inside nose cone. Though very small, compared with traditional turbine, its stronger power-making ability has won Hummer's reputation in market. Refined material, strong structure and mature techniques ensure its toughness in wild field.
Due to its small size and light weight, thus easy to carry, it is a favor to people who ofter travel, places that do not require high power supply, like observation site, TV transmission station.
By an net weight of 25kg, H3.8-2000W 's wind energy utilization ratio is as high as 0.45 while generator efficiency is > 0.8. It is capable of meeting a normal family's basic power need.
H3.8-2000W's yaw shaft is made of refined steel, tail pole is made of strong manganese steel, and tail wing is made of steel. These refined and high quality materials, ensure reliable deflection for protection.
16m is the ideal distance between two 2kw wind turbines.
Application of Model H3.8-2000W wind turbine
It can drive air-condition (2 horsepower), pump or other electrical appliances (≤ 2KW).
Well used in:
Housing
Telecommunication Station
TV Transfer Station
Monitoring Station (military, hydrology, observatory)
Water-pumping Station
Technical Parameter of H3.8-2KW wind turbine:
Rated power(W): 2000
Maximum output power(W): 3200
Charging voltage (V): DC 120V
Blade quantity: 3
Rotor blade material: GRP
Rotor blade diameter(m): 3.8
Start-up wind speed (m/s): 3.0
Rated wind speed (m/s): 9.0
Rated rotation speed (r/min): 450
Wind energy utilizing ratio (Cp): 0.45
Generator output: Single-phase AC of variable frequency
Rated charging current (A): 16.7
The maximum charging current (in a short time)(A): 28
Output AC frequency (Hz): 0-370
Generator efficiency > 0.8
Tower height(m): 10
The weight of generator(kg): 25
Battery (12V 150Ah/200Ah): 10PCS.
Anhui Hummer Dynamo Co., Ltd., is a professional wind generators manufacturer with high-tech in the field of wind energy. We specialize in researching, developing, producing and promoting of small-sized wind generator system, and also provide solutions for setting up small-scaled wind farm. After nearly 30 years of unremitting efforts, our company has developed independent intellectual property rights of "Hummer" wind generator and control system.
There are more than 200 employees in the company including 40 R&D staff. And the new factory covers over 30, 000 square meters with the first workshop more than 3100 square meters has been put into use in August, 2007. There are more than 30 sets of large machines for processing, cutting and spray-painting equipments, and also many testing and examining systems. The monthly output is 3, 000 sets.
Hummer middle and small-sized wind generators including 400W, 500W. 1kw. 2kw. 3kw. 5kw. 10kw. 20kw, 30kw, 50kw, etc have acquired CE certificate. Meanwhile, Hummer wind generator with good reputation can be found in more than 91 countries and regions, such as EU, North America, Oceania, Africa and Asia.
Hummer's wind generators have the features of "Super Light, Small, Swift and High efficiency" when comparing with traditional'. We have a powerful R&D team (consisting of experts enjoying government allowance), providing a reliable strength for product upgrade& technical support. The management team has abundant experiences in production, marketing, service and consultation. Until now our company has formed a comprehensive management system of research, study, development and service.
Hummer aims to be the best domestic manufacturer and service provider as well as a worldwide influential enterprise.
