| Price: | Negotiable/Piece |
|---|---|
| Trade Terms: | FOB,CIF |
| Min Order: | 1/Piece |
| Pay Type: | L/C,T/T |
| Model No. | WY1200 | WY2GF-1 | WY2GF-3/2GF-4 | WY2.5GF-3/2.5GF-4 | WY2.8GF-3/2.8GF-4 |
| PICTURES | Bitmap | Bitmap | Bitmap | Bitmap | Bitmap |
| Generator | |||||
| Noise(7meters away) | 63db | 65db | 65db | 70db | 71db |
| Rated output frequency | 50hz | 50hz | 50hz | 50hz | 50hz |
| Rated output voltage | 220v | 220v | 220v | 220v | 220v |
| Rated ouput power | 0.9kw | 2.0kw | 2.0kw | 2.50kw | 2.80kw |
| Max Output Power | 0.95kw | 2.2kw | 2.2kw | 2.7kw | 3.0kw |
| Engine | |||||
| Engine Model | 156F | 168FB | 168FB/168F-2D | 168FB/168F-2D | 170F/170FD |
| Engine type | 4-stroke single -clinder, air-cooled | ||||
| BorexStroke (mm) | 56x40 | 68x54 | 68x54 | 68x54 | 70x56 |
| Displacement(ml) | 98.5 | 196 | 196 | 196 | 212 |
| Compression Ratio | 8.0: 1 | 8.5: 1 | 8.5: 1 | 8.5: 1 | 8.5: 1 |
|
Theoretical Maximum Output Power |
2.2kw/3600rpm | 4.8kw/3600rpm | 4.8kw/3600rpm | 4.8kw/3600rpm | 5.2kw/3600rpm |
| Rated output power | 1.5kw/3600rpm | 3.8kw/3600rpm | 3.8kw/3600rpm | 3.8kw/3600rpm | 4.2kw/3600rpm |
| Continuouse Operating | 6.0hr | 2.8hr | 13hr | 10.3hr | 9.3hr |
| Horse Power | 3Hp | 6.5Hp | 6.5Hp | 6.5Hp | 7.0hp |
| Max Torque | 4.8N. m/3000rpm | 11N. m/3000rpm | 11N. m/3000rpm | 11N. m/3000rpm | 11.5N. m/3000rpm |
| Ignition system |
Transistorized Magneto |
Non-contact Transistorized Magneto(TCL) |
Non-contact Transistorized Magneto(TCL) |
Non-contact Transistorized Magneto(TCL) |
Non-contact Transistorized Magneto(TCL) |
| Start System | Recoil Start | Recoil Start /Electric Start | |||
| Air Cleaner | Semi-dry type | Semi-dry type /Oil bath type | |||
| Fuel Tank Capacity | 4.0L | 3.7L | 15L | 15L | 15L |
| Fuel Consumption | 0.65L/h | 1.22L/h | 1.13L/h | 1.45L/h | 1.6L/h |
| Oil Capacity | 0.4L | 0.6L | 0.6L | 0.6L | 0.6L |
| Packing Detail | |||||
| Dimension (LXWXH)mm | 495x380x420 | 610x460x470 | 610x460x470 | 610x460x470 | 610x460x470 |
| Net Weight | 20.5KG | 36KG | 45/47KG | 47/49KG | |
| Prod Model: | 2000/WY2GF-1/WY2GF-3/2GF-4 |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Warranty: | One Year, Spare Parts |
| Gas Source: | Gas |
