2g/hr Enamel tube (water cool)
Oxygen flow capacity(L/min) 1 2 3 oxygen Ozone concentration(mg/L) 28 20 16
Ozone output(g/H) 1.6 2.4 2.8
Purity: >92% Dew point of oxygen source: : -40~-60c Outlet pressure: ≤ 0.05Mpa
Item: PDMET2
Ozone output: 2000mg/hr (oxygen resource)
Generator tube size: 13.5*6*6 cmTube diameter: 3.4cm
Generator Power size: 138*56*40Mm
Voltage: AC: 110-250V. DC12V, DC24V
Ozone output in unit discharge area for 1200G/M2/h (oxygen source), up to international advanced level.
Ozone concentration with oxygen source at room temperature can be up to 120mg / L or more. It is an ideal ozone generator device making ozone water occurrence Ozone concentration in water 1.2mg / L or more.
Narrow air gap discharge, high efficiency, low heat, cooling water temperature on the ozone yield little effect.
Can be used with pure oxygen, oxygen-rich (PSA oxygen), the joint use of dry air.
