Cummins series generator introduction
Cummins is the maximal manufacturer of diesel engine up 50hp, has big developing in Japan, China and India from 1990 when Cummins start invest large capital on those countries. Cummins Chongqing is joint venture enterprise with Cummins USA, it's locate in Chongqing China whose lead product are N, K and M11 serial diesel engine using on land and ship, output power from 145kw to 1343kw they are using abroad for heavy truck, passenger car, project machine and generator. All of those product are warm welcome domestic and abroad because it's economic cost, powerful output, steady capability, longterm service and environment-friendly.
Engine:
Cummins Engine: 4 strokes, direct injection, water-cooled, exhaust turbocharging, inter-cooling.
Alternator:
World-famous Brand: Stamford, Marathon, Leroy Somer, Kaijieli,
Type: Brushless, Self-exciting, Class 4, Self-ventilating, Rotating Magnetic Field,
Protection Grade: IP23,
Insulation Class: H, Single Bearing.
Control Panel:
1. LCD Screen, Chinese and English Display, Easy Read and Program
2. Programmable
3. Hand or Anatomically Start up(Shut down)
4. Engine and Alternator Parameters Showed Digitally
5. Running Status Supervising and Control
6. Analog and Digital Input, 28 kinds of failure alarm and shut down protection
7. Input and output control of generator's accessoAV equipments
8. Intelligence remote control (RS232/485 interface for option)
9. Modern, Modbus protocol remote control
10. Control system customization available.
|
TECHNICAL DATA(50HZ) |
|
GENSET MODEL |
GFS-8 |
GFS-10 |
GFS-12 |
GFS-15 |
GFS-20 |
|
DIESEL ENGINE MODEL |
YSAD380 |
YD480 |
YD485 |
YSD490Q |
Y4100 |
|
Engine Characters |
Water-cooled, in line, 4 cycle, direct injection, 1500rpm |
|
Bore/Stroke(mm) |
80/85 |
80/90 |
85/90 |
90/100 |
100/115 |
|
Rated Output(KW) |
10 |
13.2 |
15 |
21 |
27 |
|
Fuel Consumption(g/kw.hr) |
≤247 |
≤250.2 |
≤248.90 |
≤247.5 |
≤237 |
|
Lube Consumption(g/kw.hr) |
≤2.72 |
|
Compression Ratio |
18 |
|
Starting |
Electric(12V) |
|
ALTERNATOR TYPE |
YHG164B |
YHG164C |
YHG164D |
YHG184E |
YHG184F |
|
Rated Power(KW) |
8 |
10.8 |
12.8 |
15 |
22 |
|
Voltage(V) |
230/400 |
230/400 |
230/400 |
230/400 |
230/400 |
|
Current(A) |
14.4 |
18 |
21.6 |
27 |
36 |
|
Frequency(Hz) |
50 |
|
Power Factor(cosφ) |
0.8 |
|
Dimensions(LXWXH)mm |
1660x800x950 |
1660x800x950 |
1830x880x950 |
1830x880x950 |
2000x900x1040 |
|
Net Weight (kg) |
650 |
700 |
750 |
800 |
900 |
|
TECHNICAL DATA(60HZ) |
|
GENSET MODEL |
GFS-8 |
GFS-10 |
GFS-12 |
GFS-15 |
GFS-20 |
|
DIESEL ENGINE MODEL |
YSAD380 |
Y385 |
YD480 |
YSD485 |
YSD490Q |
|
Engine Characters |
Water-cooled, in line, 4 cycle, direct injection, 1800rpm |
|
Bore/Stroke(mm) |
80/85 |
85/90 |
80/90 |
85/90 |
90/100 |
|
Rated Output(KW) |
11 |
12.6 |
15.8 |
18 |
25 |
|
Fuel Consumption(g/kw.hr) |
≤247 |
≤262.5 |
≤250.20 |
≤248.90 |
≤247.50 |
|
Lube Consumption(g/kw.hr) |
≤2.72 |
|
Compression Ratio |
18 |
|
Starting |
Electric(12V) |
|
ALTERNATOR TYPE |
YHG164B |
YHG164B |
YHG164C |
YHG184D |
YHG184E |
|
Rated Power(KW) |
8 |
10.8 |
12.8 |
15 |
22 |
|
Voltage(V) |
230/400 |
230/400 |
230/400 |
230/400 |
230/400 |
|
Current(A) |
14.4 |
18 |
21.6 |
27 |
36 |
|
Frequency(Hz) |
60 |
|
Power Factor(cosφ) |
0.8 |
|
Dimensions(LXWXH)mm |
1660x800x950 |
1660x800x950 |
1660x800x950 |
1830x880x950 |
1830x880x950 |
|
Net Weight (kg) |
650 |
680 |
700 |
750 |
800 |
Beijing Avespeed Commercial & Trading Co., Limited is the leading manufacturer and supplier of diesel engines for marine propulsion, marine Gen-sets, stationery Gen-sets and power plant applications in China. AVESPEED manufactures diesel engines with unit output from 150KW to 4500KW, which can be used as propulsion of merchant vessels and special vessels from 1000 to 30000 tons DWT. AVESPEED manufactures marine auxiliary diesel generators with unit output from 150KW to 4500KW and stationery HFO generators with unit output from 500KW to 8000KW.
AVESPEED designs and builds turn-key power plant with an output up to 100MW as base load power plant, peaking power plant or industrial self-captive power plant in cement, textile, mining or oil and gas industries etc. The power fuel can be diesel oil, bio-diesel, heavy fuel oil (HFO) or bi-fuel. AVESPEED has been set up more than 200 heavy fuel oil (HFO) power plant projects in the world in recent years, especially in Nigeria, we have set up more than 60 HFO power plant projects there.
All of our marine diesel engines have achieved type approvals and work test approvals of, CCS, China Ships Inspection Bureau, and China Fishing Ships Inspection Bureau. Many products are rated as "National Grade New Products" and "Industry Brand Products" and awarded with "National Prize for Progress in Science and Technology", Now AVESPEED diesel engines are widely used for deep sea fishery, inshore fishing ships, ocean shipping, inland water navigation, passenger cargo ship transport, harbor tug, engineering ships, enforcement ships, naval auxiliaries etc.
New energy products developed in recent years including natural gas generator sets, biomass generator sets, tyre oil/vegetable generator sets and dual-fuel generator sets with unit output from 50KW to 1000KW.
AVESPEED also involves in the development and manufacture of the crystal silicon (mono and poly) solar panel/module, photovoltaic system, and other photovoltaic products. We supply solar panels ranging from 45W to 290W. AVESPEED's on-grid and off-grid inverters are the sole in China certified by TUV. The PV inverters range from 1KW to 1000KW.
Our products and manufacturing processes fully comply with product safety requirements, including TUV/IEC61215 & 61730, CSA/UL1703, MCS, CE and UKAS. Additionally, we have implemented best practices to protect the environment and conserve energy.
So far, our customers spread dozens of countries and regions in Europe, Middle East, Africa, South America, Southeast Asia and West Asia. AVESPEED is willing to cooperate with relevant famous enterprises and far-sighted, strong-willed and talented people at home and abroad by supplying our high-quality products and excellent service.
