Model: FD10-20kw & FD12-20kw
Rotor Diameter: 10m or 12m
Number of Blades: 3PCS
Material of Blades: Fibre glass expoxy
Cut-in wind speed: 3m/s
Working wind speed: 4-30m/s
Survival wind speed: 50m/s
Rated wind speed: 12m/s (FD12 rated wind speed is 9.8m/s)
Rated rotation speed: 170r/min (FD12 is 150rpm)
Rated output power: 20kw
Max output power: 30kw
Type of tower: Independence tower/Guy wire tower
Type of generator: Permanent-magnet 3 Phase AC
Speed regulation method: Yaw
Stop method: Manual brake/auto brake
Working voltage: DC500V
Tower height: 15m or special rquest
Wind turbine main body weight: 1300kg
Life span: 15 years
Warranty: 2 years
Working system: Off-grid working system/on-grid working system
You can take the whole system from us, also you can take any parts of the system from us.
For on-grid working system, we can provide wind turbine, on grid controller. We provide the generator actual test data, then you can get the inverter from local.
Ningjin huaya industry Co., Ltd. is specialized manufacture of small wind turbine generator.
Form the first 50W, 100W wind turbine to 300W-20kw wind turbine, we past 15 years. Now we have the steady off-grid working system, 1kw, 2kw, 3kw, 5kw, 10kw, 20kw on-grid working system. To provide the steady system is our aim.
Blades:
The blade form is chosen by wind tunnel test. The aerofoil with the highest wind speed utilization ratio is used. The wind energy transfer efficiency can reach 0.42.
Generator:
ND-fe-b permanent magnet. Packaged type tangential grinder magnetic circuit rotor; High magnetic flux density, small cubage, good manufacturing technics and high capability.
Adopt Sweden SKF bearing.
Close transmission slip ring, the cable will not enlace
Tower:
Tower with guy wires, tilting up tower, hydraulic tower, independence tower. It can be designed according to your request.
Now the wind turbine system is working in more than 30 countries. To provide the good, steady system is our aim.
For more products details, pls contract with us! We will provide you quickly and professional feedback.
