20kVA Siemens alternator generator specification:
Modle: 1FC2 182-4
Prime power: 20kVA/16KW
Standby power: 25/20KW
Dimension: 680*398*487mm
Weight: 140kg
Rated Voltage: 400/230V, 450/260V
Speed: 1500/1800rpm
Frequency: 50/60Hz
Output Type: AC Three Phase
Power factor (Cos Phi): 0.8```1
Altitude: ≤ 1000 m
Efficency(%): 2/4: 86.3, 3/4: 84.5, 4/4: 82.2
AVR model: EA04C
Number of phase: 3
Overspeed: 1875r/min
Exciter type: AREP
Sustained short circuit current: 300% (3 IN): 3s
Insulation class: H
Protection class IP23
Voltage regulation: ± 0.1%```± 0.5%
Total harmonics (TGH/THC): < 4 %
Wave form NEMA = TIF: < 50
Wave form i. e. C. = THF: < 4%
Bearing: Single
Coupling: Direct
Other products we can offer:
As a big OEM factory specialized in manufacturing, sales and leasing Services. We can provide Diesel Generator Set, Portable Generator, Silent Generator Electric Generator, Natural Gas Generator under the famous brand of CUMMINS, DEUZT, CATERPILLAR, SHANGCHAI(SEDC), YUCHAI, with power ranging 0.65-3000kVA; AC alternator under the brand of STAMFORD, MARATHON, FARADAY and Siemens. We also offer spare parts for SFH, SEDC and HINO.
the supplied list of Siemens high voltage generator |
Modle |
400V/50Hz |
400V/50Hz |
1500RPM |
1800RPM |
KVA |
KW |
KVA |
KW |
1FC2 181-4 |
15 |
12 |
20 |
16 |
1FC2 182-4 |
20 |
16 |
25 |
20 |
1FC2 183-4 |
25 |
20 |
30 |
24 |
1FC2 184-4 |
30 |
24 |
37.5 |
30 |
1FC2 185-4 |
37.5 |
30 |
47.5 |
38 |
1FC2 186-4 |
50 |
40 |
60 |
48 |
1FC2 221-4 |
62.5 |
50 |
80 |
64 |
1FC2 222-4 |
80 |
64 |
100 |
80 |
1FC2 223-4 |
94 |
75 |
107.5 |
86 |
1FC2 224-4 |
112.5 |
90 |
143.8 |
115 |
1FC2 281-4 |
150 |
120 |
187.5 |
150 |
1FC2 282-4 |
187.5 |
150 |
235.5 |
188 |
1FC2 283-4 |
250 |
200 |
275 |
220 |
1FC2 284-4 |
312.5 |
250 |
330 |
264 |
1FC2 351-4 |
375 |
300 |
420 |
336 |
1FC2 352-4 |
400 |
320 |
480 |
384 |
1FC2 353-4 |
450 |
360 |
540 |
432 |
1FC2 354-4 |
500 |
400 |
600 |
480 |
1FC2 355-4 |
625 |
500 |
696 |
557 |
1FC2 451-4 |
750 |
600 |
825 |
660 |
1FC2 452-4 |
875 |
700 |
984 |
787 |
1FC2 453-4 |
1000 |
800 |
1200 |
960 |
1FC2 454-4 |
1250 |
1000 |
1500 |
1200 |
1FC2 561-4 |
1472 |
1178 |
1766 |
1413 |
1FC2 562-4 |
1690 |
1352 |
2028 |
1622 |
1FC2 563-4 |
1962 |
1570 |
2354 |
1883 |
1FC2 564-4 |
2500 |
2000 |
750 |
2200 |
1FC2 565-4 |
2750 |
2200 |
3025 |
2420 |
