20g/hr Enamel tube (water cool)
Oxygen flow capacity(L/min) 1 3 5
Ozone concentration(mg/L) 86 76 68
Ozone output(g/H) 5.1 13.6 20.4
Oxygen purity: >92% Dew point of oxygen source: : -40~-60C Outlet pressure: ≤ 0.05Mpa
Item: PDMET20
Ozone output: 20g/hr (oxygen resource)
Generator tube size: 44*6*6 cm Tube diameter: 3.5cm
Generator Power size: 21.5*10*7.5 cm
Voltage: AC: 110-250V. DC12V, DC24V
Ozone output in unit discharge area for 1200G/M2/h (oxygen source), up to international advanced level.
Ozone concentration with oxygen source at room temperature can be up to 120mg / L or more. It is an ideal ozone generator device making ozone water occurrence Ozone concentration in water 1.2mg / L or more.
Narrow air gap discharge, high efficiency, low heat, cooling water temperature on the ozone yield little effect.
Can be used with pure oxygen, oxygen-rich (PSA oxygen), the joint use of dry air.
