2014 Hot Selling Coal gas Producing equipment--Coal Gsifier/Coal Gas Generator
Introduction:
Our company designs the manufacturer producer gas generator, is take the air and the steam as vaporization medicinalpreparation, production combination gas advanced equipment, this equipments suits the vaporization coking coal, fuel and so on .widely applies in machine, metallurgy, chemical industry, glass, building materials, light industry, food, textile industry heating dry kiln.
Features:
1. Using pagoda-shaped heat-resistant iron grate;
2. The furnace wall is always protected by slags, strong effect of slag breaking, slag loosing and ventilation;
3. Our coal gasifier eliminates the concept that gas furnace is the same as pressure vessel;
4. Our coal gasifier achieve tha auto control of the temperature.
Working principle:
0-80mm pea coal is the ideal fuel for the continual coal gasifier, which largely increases the gasification intensity, accelerates the reaction, improves the gasification rate of coal, and makes charcoal react with vapour to form combustive air such as carbon monoxide and hydrogen, so as to reach complete gasification and produce gas continually and steadily.
Main technical parameters:
Model
QM0.8
QM1.0
QM1.2
QM1.5
QM1.6
QM1.8
QM2.0
QM2.4
QM2.6
QM3.0
QM3.2
Chamber diameter(mm)
800
1000
1200
1500
1600
1800
2000
2400
2600
3000
3200
Hearth active surface(m2)
0.5
0.785
1.13
1.77
2.01
2.54
3.14
4.52
5.31
7.07
8.04
Suirable fuel
weak coherent gas carbon,anotherracite,burnt carbon
Fuel granularity(mm)
25-80
Fuel consumption quantity(kg/h)
40-100
70-140
120-190
160-350
350-460
500-600
500-720
700-1040
850-1200
1700-2000
1800-2200
Gasifying agent
Air ,steam
Gas yieldNm3/h)
140-350
245-490
420-670
560-1200
1200-1600
1500-2100
1750-2500
2500-3600
3000-4300
6000-7000
6500-7500
Gas calorific value(Kj/Nm3)
5020-5670
5020-6000
Water jacket heating area(M2)
4.02
5.02
6.78
10.37
11.06
12.44
17.58
21.87
23.69
30.16
32
Steam output(kg/h)
60
80
130
200
220
260
350
420
600
840
200
Gas outlet temperature(degrees centigrade)
(400-500)Plants related with the coal
(400-500)Plants related with the coal
Gas outlet pressure(Pa)
1000
980-1470
1470-1960
980-1470
Gas exportation diameter(mm)
219
325
325
426
426
529
630
720
820
1020
900
Air pressure(Pa)
3000
4000
3000
Saturated air temperature(degrees centigrade)
50-60
50-65
Ashpan rotational speed(r/h)
0.177-1.77
Equipment gross weight(t)
3.5
4.5
5
7.5
10
20
23.4
29.8
32
37.6
16
Complete machine power(kw)
6
6
6
7
8
10
14
20
20
27
7
Tuyere diameter(mm)
108
108
140
165
219
325
325
426
426
426
219
Henan Dajia Mining Machinery Co., Ltd (the former Henan 3rd Machinery Factory founded in 1902) is one leading manufacturing enterprise in China and the key enterprise in mechanical industry and Zhengzhou City. After joint-stock system reform, Henan Dajia Mining Machinery Co., Ltd is established, focusing on the design and manufacture of mining machine, complete preparation equipment, rotary kiln and construction facilities, etc. With the advantages of many years' Development, we now have rich experience and powerful strength in independent design and manufacture of stone crusher, ball mill, ore separator and complete plants of cement production, limestone production and ceramsite production, and we have also passed international quality system certification.
Our products are widely applied in industries such as mining, manufacturing, mineral concentration, metallurgy, chemicals, water conservation, road and bridge constructions. Now we become the local largest manufacturer of complete ore concentration plant. With the advanced inspection equipment and strict quality guarantee system, we passed the ISO9001 certifications early in 1997 and passed ISO9001: 2000 certifications in 2003.
Currently, we have built a full product chain of 5 series with near 30 kinds including stone crushing, sand making, ore separating, cement manufacturing, basing on the main products like crusher, ball mill, rotary kiln, and assisting by vibrating screen, vibrating feeder and dust collector, etc. The advantages of high technology, higher reliability and lower operation and maintenance cost make our products the leading industrial position. Our products have been used for the international mining and construction industries in more than 40 Countries. We own a sale and service team with rich experience and good technology and an integrated sale and service network. With our high quality products and sincere service, we are recognized and praised by our customers, the mining industry and our competitors.
Henan Dajia welcome everybody all over the world.
