2013 New vertical wind turbine (SEW-300)
1. Low start-up wind speed.
2. High efficiency, long life,
3. Easy to install
4. CE
Notice:
All specifications are subject to change without further notice.
Installation of wind power generator system must comply with the laws and regulations in your area, or the consent of the local government.
Installation, maintenance and demolition of wind power generation system must under the no wind weather.
Wins power generation system including machinery and electronic equipment, make sure the professional construction workers and be safe.
Picture color or shape may have physical discrepancy.
Don't make wind generator operation in No-loading (no connection battery and load) state.
This manual involved in safety mark as follows.
Danger: Improper operation will likely cause serious personal injury
Caution: Improper operation will likely lead to product damage or personal injury.
Product introduction
EW series wind generator is small full time operation wind power generator, with small size, easy to installation and use, low cost and higher efficiency and performance etc. Therefore, it's suitable for different kinds of regional and various climate environments.
II, Performance characteristics
Wind generator controller with intelligent and modular design, simple structure and powerful, reliable and stable performance
The Perfect Protection Function
Wind blades is made from glass reinforced polypropylene material
Wind generator adopt aluminum alloy material, and the weight of the generator is about 16KG
Wind generator adopt unique shock profe design, smooth operation
Wind generator connect the tower with flange, simple and reliable
|
Parameter |
|
Model |
SEW-1000 |
SM-300 |
SEW-600 |
|
Rated power(W) |
1000 |
300 |
600 |
|
Rated voltage(V) |
24\48 |
12\24 |
24\48 |
|
Rated current(A) |
41/20 |
25/12.5 |
25/12.5 |
|
Rotor diameter(m) |
1.96 |
0.82 |
1.73 |
|
Start-up wind speed (m/s) |
2.5 |
1 |
2.5 |
|
Rated wind speed(m/s) |
12 |
35 |
12 |
|
Survival wind speed(m/s) |
35 |
|
35 |
|
Working form |
permanent magnet synchronous |
|
permanent magnet synchronous |
|
Rotating direction |
Clockwise |
Generator life (year) 15-20 |
Clockwise |
|
Blade NO.(Piece) |
3 |
6 |
3 |
|
Blade material |
Nylon |
Glass fiber reinforced plastic |
Nylon |
|
Tower height (m) |
6 |
6 |
6 |
|
Suggest supporting capacity battery |
12V200AH * 2 |
Generator gross(kg) 15 |
12V200AH * 2 |
|
Supporting inverter type |
Single-phase sine wave |
Tower height (m) 6 |
Single-phase sine wave |
|
|
|
|
|
|
Model |
SEW-300 |
SEW-400 |
|
|
Rated power(W) |
300 |
400 |
|
|
Rated voltage(V) |
12\24 |
12\24 |
|
|
Rated current(A) |
25/12.5 |
33/17 |
|
|
Rotor diameter(m) |
1.5 |
1.5 |
|
|
Start-up wind speed (m/s) |
2.5 |
2.5 |
|
|
Rated wind speed(m/s) |
12 |
12 |
|
|
Survival wind speed(m/s) |
35 |
35 |
|
|
Working form |
permanent magnet synchronous |
permanent magnet synchronous |
|
|
Rotating direction |
Clockwise |
Clockwise |
|
|
Blade NO.(Piece) |
3 |
3 |
|
|
Blade material |
Nylon |
Nylon |
|
|
Tower height (m) |
6 |
6 |
|
|
Suggest supporting capacity battery |
12V150AH * 2 |
12V150AH * 2 |
|
|
Supporting inverter type |
Single-phase sine wave |
Single-phase sine wave |
|
