1)Off-grid AC-DC power supplying system.
2)The system uses microprocessors and Specialized Control Algorithms to reach intelligent control.
3)Multiple AC and DC output interface to achieve multiple purposes: 1*24V DC, 1*20V DC, 2*12V DC, 1* 9V DC, 2*5V USB, 3* 220V AC.
4)Scientific power charging and discharging protection, high accuracy of temperature compensation enables more accuracy of charging control.
5)LCD can display battery voltage and AC output voltage, allowing users to get real-time system status.
6)Over charged, over discharged, overloaded protection with unique electronic short circuit protection and anti-reverse protection.
7)It can be both charged by solar panel and AC power charger adapter.
8)Electricity generated per day: Approximately 0.6KWH in sunny weather.
9)Electricity consumed per day: Maximum power consumption 1.8 KWH.
10)Extensibility: This system also can be charged by solar modules of 300W or below to achieve rapid charging.
|
No. |
Components |
Specification |
Unit |
QTY |
Life Span |
|
1 |
Solar Panel |
200W/36V |
PC |
1 |
25 years |
|
2 |
Solar Charger Controller |
24V/10A |
PC |
1 |
5 years |
|
3 |
Inverter |
24V/500W Sine Wave |
PC |
1 |
5 years |
|
4 |
Power Control Cabinet |
460*480*500MM |
PC |
1 |
Long term |
|
5 |
Brackets for Panel |
|
SET |
1 |
Long term |
|
6 |
Storage Battery |
12V100Ah, Lead-Acid |
PC |
2 |
3 years |
|
7 |
Power Supply Cable |
4mm2*2 |
M |
10 |
|
|
Loads |
Model |
Power |
QTY |
Working time |
Power consumption
per day |
|
Light |
energy-saving lamp |
DC10W |
6 |
6 |
360WH |
|
Mobile Phone |
Charging current 400mA |
DC2W |
4 |
5 |
40WH |
|
Satellite TV Receiver |
|
AC25W |
1 |
4 |
100WH |
|
TV |
21’ |
AC50W |
2 |
4 |
400WH |
|
Fan |
|
AC30W |
2 |
4 |
240WH |
|
Laptop computer |
|
AC65W |
2 |
3 |
390WH |
|
Total |
DC68W+AC315W=383WH |
|
1530WH |
