20" Square Barrier Filter Panel,high performance and economy
Filter Media
Heavy-duty cellulose media/ Glass fiber
Replacement P14-6555 with high performance unit is the same one we put into first-fit systems for our OEM customers. It contains over 100 sq. ft. of heavyduty cellulose media, is structurally strong via polymer pleat spacers, and is built for long life and high efficiency at low ΔP.
The economical P53-4557 replacement panel contains almost 50 sq.ft. of fiberglass media, and has metal spacers for structural stability.
Specifications
？ Efficiency: F8 / 90-95% ASHRAE
(see table on page 30)
？ Shape: square
？ Dimensions: 20 x 20 x 5 inches / 508 x 508 x 127 mm
？ Rated Airflow: 1300-2000 cfm
？ Liners: aluminized steel
？ Carton Weight: 20 lbs
Other Size Available
| DIMENTIONS |
| Model | Width (mm) | Hight (mm) | Depth (mm) | Shape | Frame |
| TN22424041 | 610 | 610 | 102 | Square | Beverageboard |
| TN22424030 | 610 | 610 | 89 | Square | Beverageboard |
| TN22424042 | 610 | 610 | 102 | Square | Metal |
| TN22424043 | 610 | 610 | 102 | Square | Metal |
| TN21724040 | 444 | 610 | 102 | Rectangle | Beverageboard |
| TN22924040 | 738 | 610 | 102 | Rectangle | Metal |
Customized sizes are available on request
Thenow was established in 2005, belongs to Apureda Group as the wholly-owned subsidiary. Being a standard maker, Apureda Group is a global specialist in the development and production of filtering systems and solutions with 6 production units.
As one of Apureda Group's production units, Thenow's business is to provide customers with sustainable best-in-class air filtration products and services. We mainly focus on manufacturing industrial filters including dust collector filters, gas turbine intake air filters, oil mist collectors and air purifying filters.
Our business concept is to optimize our product quality and service in line with customer needs. Compared with standard filters, Thenow's products can reduce the operating costs of filtration systems, which keep their pressure drop low over a longer time. Our filters can catch more contaminants and operate at lower average resistances because of better designed filter media and larger filter media surface. Thenow's products are widely used in various fields such as petroleum, chemical industry, steel, paint, electronics industry, pharmaceutical industry, shipping, cement, gas turbine etc.
We are reliable because we know the market, we are honest and truthful. Our people, products and processes must always meet, or supersede, agreed results.
Thenow's qualified staffs is glad to support the customers in all matters concerning the efficiency and operations of our products. We provide our customers in very diverse sectors of industry with maximum benefit from our top-quality filters installed in their highly-complex plant. The flexible, customized package comprises a comprehensive filter program plus service support plus warranties - all at guaranteed fixed costs to bring our partners system solutions that are innovative, high-performance, economically efficient, environmentally friendly and offer excellent value for money.
- Technical service support and maintenance of mechanical and electrical system components
- Filter acceptance measurements
- Measuring dust emissions and immissions
- Technical acceptance testing of the filter and ventilation systems
- Checking the systems' technical condition, weak-point analysis
- Documentation of all work performed
