Gasoline Generator Engine Powered by HONDA
Gasoline Generator Detail Description
>40% more silent than normal quality Gasoline generator
>Professional team new designs
>Unique design on the generator market
BMW's quality, TOYOTA's price.
1 Key Spare Parts like Crankcase, Cylinder Head ,and others all used for Honda Original Gasoline Generator
2 A+++ Carburetor from one of top Chongqing brands.
3 New design Contral Panel with back cover and both side Protrction Panel, beautiful, heat insulation and rain-proof.
4 High quality silencer with new technology
5 100% copper alternator with full 100% power output 2KW and 5KW.
Quiet down the generator, enjoy trouble free life with silent power.
We're sure you will get prompt attention.1. New Design, Super Silent!
2. Stable Quality
3. Hand Start(Recoil) / Key Start With Battery(E-Start) is optional
4. The voltage : 110/120/220/230/240 V
5. Power output: 1.5/1.8/2.0/2.5/2.7/2.8/3.0/3.6/4.0/4.5/5.0/5.5/6.0/6.5 KW
6. 5.5-15 HP Engine
7. Copper/ Aluminium Alternator is optional
8. Single-Phase or three phase is optional
9. New type volt-meter & current- meter, with protection double panel
10. Muffler / Silencer with low noise, Motorcycle Silencer is optional
11. Cast iron Camshaft, Cast Steel Crankshaft
12.Best quality Crankcase and Crankcase Cover
13.High Quality Carburetor
14.Galvanized shining screw, A++ grade piston
15.Strong Carton Packing, inside with Foam and Wood2.5KVA 220V Electric Start Portable Home Use Silent Gasoline Generator for Home UseLoading Photoes
Product name | China Gasoline Generator |
Generator | Rating frequency(Hz) | 50 | 60 | 50 | 60 | 50 | 60 | 50 | 60 | 50 | 60 | 50 |
Rating Voltage(V) | 110/120/220/230/240 |
|
Rating power(KVA) | 2 | 2.5 | 2.5 | 2.7 | 2.8 | 3.6 | 4 | 4.5 | 5 | 5.5 | 6 |
The Max.power(KVA) | 2.2 | 2.7 | 2.7 | 3 | 3 | 4.2 | 4.8 | 5 | 5.5 | 6 | 6.5 |
Power factor(cos) | 1 |
Engine | Type | 168F-1 | 170F | 177F | 182F | 188F | 190F |
Model | 5.5HP | 6.5HP | 9.0HP | 11.0HP | 13.0HP | 15.0HP |
Category | Single crock,Force air-cooled four-stroke,top-intalled gasoline engine |
Exclusion of cylinder(cm3) | 163 | 196 | 270 | 337 | 389 | 407 |
The Max.output power(KW/rpm) | 4.8/3600 | 5.7/3600 | 7.0/3600 | 8.0/3600 | 9.5/3600 | 11.0/3600 |
Ignition system | Transistorized magneto |
Start system | Recoil/E-start |
Capacity of fuel tank(L) | 15 | 15 | 25 | 25 | 25 | 25 |
Consumption of fuel(L/h) | 1.13 | 1.32 | 1.9 | 2.45 | 2.7 | 2.95 |
Consecutive Working(h) | 13 | 11 | 13 | 10 | 9 | 8 |
Noise(at7m)(dB) | 65 | 65 | 69 | 72 | 74 | 78 |
Capacity of engine oil | 0.6 | 1.1 |
Dimension | Set dimension(mm3) | 615×435×455 | 615×435×455 | 620×470×480 | 635×510×485 | 670×510×510 | 692*522*545 |
Net weight(kg) | 39 | 40 | 62 | 78 | 80 | 85 |
Standard Equipment | Large capacity fuel tank,large capacity muffler,fuel gauge,voltmeter,AVR,oil alert,Ac circuit breaker
|
Purchasing | Four-wheel dolly kit | Yes |
ANDITIGER is from reliable brand ANDI, which is established in beautiful seaside city of Taizhou Zhejiang, China, 2003, professional in producing generator, water pump & engine. Owning self brands ANDI, ANDITIGER, ELEFUJI etc. The products are favourable in Europe, Middle East, Africa, South East Asia, all over the world.
During the hard time of developing silent generators since factory established. Once a day, the founder went to visit a friend, when they were talking in the room, suddenly, the power stopped, the host started his back-up generator but full of noise. Immediately, a crying came from a sleeping baby, all people dropped in a mass. In that case, the founder brought a self-researched silent generator and started it, amazingly, the baby stopped crying at once, the whole room became quiet, the baby slept again with smile. It seems like all people enjoyed the nice silent generator.
Since then, the founder firmed the faith_Build number one silent generator!
