Hydrogen fuel cell generator Price Introduction:
Past CE Certificate
SPE series hydrogen generator, is with world advanced SPE/PEM technology. PEM full name is Proton Exchange Membrane. Also called SPE technology ( solid
Polymer electrolyte). Through. Electrolysis pure water( no need to add chemicals) to produce high purity
Hydrogen. This machine is light, high effective,
Energy saving and environmental protection. And world advanced patent right products.
99.99999%, 0--7bar pressure!
SPE/PEM technology Advantages:
1. PEM technology---Proton Exchange Membrane
2. The PEM electrodes, as the core of the product, are highly active catalytic electrode with nearly zero distance between the electrodes, which is formed by integrating
Composite catalyst with ion membrane with high electrolytic efficiency.
3. Plural-electrode and multiunit electrolysis cell structure.
Excellent chemical technological process properties of heat and mass transfer.
4. Electrolysis of pure water( no adding alkali) to produce high purity (99.999%/99.9995%) hydrogen with no corrosion and pollution.
5. Voltage of cell is low, electronic resistance in the electrolysis cell is little,
Could greatly saving energy. Circle time for changing desiccants is long.
6. Power consumption is less, electrolysis is efficient
7. Hydrogen output flow under stable pressure. Gas produced on demand,
No storage.
TH -300/500/1000 Main Characters:
1. World advanced "SPE" technology ( solid polymer electrolysis)
2. No chemical(KOH or NaOH ) inside. Directly electrolysis pure water. Protect GC column.
3. Use proton exchange membrane from USA "Dupont" brand
4. Inside use silicon rubber rings ( lower sulphur content), increase gas output purity, guarantee GC basic line stable.
5. Output pressure and gas output display both use integration control.
6. Automatically water level control, when short of water, machine auto stop working, greatly
Protect electrolysis cell lifetime.
7. Could meet all brands GC working requirement at home and abroad.
Why Choose Us?
1. TH series H2 generator, No KOH, Only electrolysis pure water to produce pure hydrogen gas.
2. World mostly advantaged technology for producing H2 gas.
3. We already produce for 17 years
4. Green and utmostly protect your GC instrument
5. Environment friendly, no polution.
Model |
TH-300 |
TH-500 |
TH-1000 |
Output H2 flow
(LCD display) |
0--300ml/min |
0--500ml/min |
0--1000ml/min |
Output H2 purity |
99.999% |
99.999% |
99.999% |
Output H2 pressure |
0.4MPa/0.7MPa |
0.4MPa/0.7MPa |
0.4MPa/0.7MPa |
Pressure Stability |
< 0.001MPa |
Using water requirement |
>2meghom.cm |
Input power |
220 / 110 ± 15%, 50--60Hz |
Power consumption(W) |
<150 |
<200 |
<400 |
Size |
400*360*220mm |
Net Weight |
14kgs |
15kgs |
18kgs |
