Foshan Tanfon Energy Technology Co., Ltd. is specialized in R&D, manufacturing and selling solar power system product, wind power system product, solar &wind hybrid system(on grid and off grid systems).
For solar system mostly use for household power supply, have main charger when non-sunshine. Very useful system. Pure sine wave output, can take all inductive loads. Product sales to (France, USA, Canada, Pakistan, UAE, Bangladesh ect) popular product and new energy leads low carbon life.
Solar on grid system: Solar panel+grid tie inverter
Solar off grid system: Solar panel+hybird inverter(controller, inverter)+battery
(other parts as PV array combiner, rack, cable can optional)
System Application:
1, Living house and home building;
2. Office building, factory and warehouse
3. Shopping mall, venue, stadium and so on
4. Power station, field operation and some huge engineer construction
Good quality, best price and better technical support and service, make Tanfon energy technology Co., Ltd as your most valuable cooperator in China.
|
Off grid solar power supply system- SP-1KW |
|
System |
Solar panel rated output power: 1KW |
|
|
Basic Information |
Suitable for daily power consumption: |
|
|
< 3200WH |
|
|
Allowable max loads power: 3KW |
|
Solar panel |
type: polycrystalline or mono solar panel |
QTY |
|
Max power: 180w |
4pcs |
|
Vmp: 43.2V |
|
|
Imp 4.96A |
|
|
Size: 1218*812*35mm |
|
|
25 years power output guarantee |
|
|
(CE TUV) |
|
|
|
|
Notes: |
|
|
|
1. pictures show are for reference. |
|
|
|
2. power output data is based on areas with daily average peak power shine of 4.5hrs |
|
|
|
3. the battery capacity is designed for power storage of 1.5-2 days PV output |
|
|
|
4. solar panel rack can be specially designed based on site condition |
|
|
|
|
|
|
|
|
|
|
|
Remark: |
|
|
|
1)solar panel have 3 years warranty; |
|
Hybrid solar Inverter |
Solar inverter with controller built it |
QTY |
2)other parts have 2 years warranty; |
|
Inverter power: 1kw/48v |
1pc |
3)ship the free parts for service(best service in china) |
|
controller: 40A |
|
4)accept OEM |
|
LCD display inverter and controller info |
|
|
|
With AC charger built in |
|
|
|
Protection against short-circuit, over load, high-voltage and low-voltage protection |
|
|
|
Output: 110v, 120v, 220v, 230v, 240v(optional) |
|
|
|
Frequency: 50HZ or 60HZ(optional) |
|
|
|
Battery |
Capacity: 12V/200AH |
QTY |
|
|
Solar power lead-acid battery, full sealed |
4pcs |
|
|
Service life: 5-6 years, |
|
|
|
Solar panel rack |
Flat – roof type mounting rack, |
QTY |
|
|
No welding/ cutting at site, |
1set |
|
|
easy mounting. |
|
|
|
More options to select: |
|
|
|
Slope-roof mounting rack |
|
|
|
Array type rack; Standing – pole type rack |
|
|
|
Cables |
International standard, |
|
|
|
with specification suitable for |
100m |
|
|
solar system, |
|
|
Foshan Tanfon Energy Technology Co., Ltd. is specialized in R&D, manufacturing and selling solar wind product and all kinds of pure sine wave inverter. As one of the leading factories in the green energy source field, Tanfon was initially established in the year of 1996. We are a professional manufacturer of green energy products including: Solar power system, wind power system, solar street light system, all kinds pure sine wave inverter(solar inverter, wind inverter, home UPS inverter ), controller, battery products., with advantage of possessing a professional R&D team to develop new wind energy turbine and inverter in concept of "Green Energy Leads Low Carbon Life".
Product sales to
(Pakistan, Nigeria, Canada, , Costa-Rica, Cyprus, Mocambique, Turkey, Malavi, Thiland, Philippines, Belgium, Indonesia, Czech Republic, Madagascar, Italy, Australia, Egypt, Tajikistan, Sri Lanka, Malaysia, France, USA, Guaemala, Switzerland, Israel ect)
We accept OEM and small trial orders, contacting with us for more information. All inquiries will be replied with in 24 hours. We also cordially welcome all clients to visit us and discuss business and place orders with us by any means of communication. We believe that with our best quality products and your marketing channel, we are certain to establish a lasting mutual beneficial cooperation relationship with you.
Good quality, best price and better technical support and service, make Tanfon energy technology Co., Ltd as your most valuable cooperator in China.
